3HVW

Crystal Structure of the GGDEF domain of the PA2567 protein from Pseudomonas aeruginosa, Northeast Structural Genomics Consortium Target PaR365C

• PDB DOI: https://doi.org/10.2210/pdb3HVW/pdb

• Classification: LYASE
• Organism(s): Pseudomonas aeruginosa
• Expression System: Escherichia coli
• Mutation(s): No


• Deposited: 2009-06-16 Released: 2009-06-23
• Deposition Author(s): Forouhar, F., Lew, S., Seetharaman, J., Sahdev, S., Xiao, R., Ciccosanti, C., Foote, E.L., Wang, H., Everett, J.K., Nair, R., Acton, T.B., Rost, B., Montelione, G.T., Hunt, J.F., Tong, L., Northeast Structural Genomics Consortium (NESG)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.70 Å
• R-Value Free: 0.219
• R-Value Work: 0.201
• R-Value Observed: 0.202

Literature

Northeast Structural Genomics Consortium Target PaR365C

Forouhar, F., Lew, S., Seetharaman, J., Sahdev, S., Xiao, R., Ciccosanti, C., Foote, E.L., Wang, H., Everett, J.K., Nair, R., Acton, T.B., Rost, B., Montelione, G.T., Hunt, J.F., Tong, L.

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 20.09 kDa
• Atom Count: 1,495
• Modelled Residue Count: 159
• Deposited Residue Count: 176
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Diguanylate-cyclase (DGC)	A	176	Pseudomonas aeruginosa	Mutation(s): 0  Gene Names: PA2567
UniProt
Find proteins for Q9I0R8 (Pseudomonas aeruginosa (strain ATCC 15692 / DSM 22644 / CIP 104116 / JCM 14847 / LMG 12228 / 1C / PRS 101 / PAO1)) Explore Q9I0R8  Go to UniProtKB:  Q9I0R8

Small Molecules

Modified Residues  1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE	A	L-PEPTIDE LINKING	C5 H11 N O2 Se		MET

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.70 Å
• R-Value Free: 0.219
• R-Value Work: 0.201
• R-Value Observed: 0.202
• Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 49.374	α = 90
b = 53.757	β = 90
c = 76.792	γ = 90

Software Package:

Software Name	Purpose
CNS	refinement
PDB_EXTRACT	data extraction
MAR345dtb	data collection
DENZO	data reduction
SCALEPACK	data scaling
SnB	phasing
REFMAC	refinement

Structure Validation

Entry History

Deposition Data

• Released Date: 2009-06-23
Deposition Author(s): Forouhar, F., Lew, S., Seetharaman, J., Sahdev, S., Xiao, R., Ciccosanti, C., Foote, E.L., Wang, H., Everett, J.K., Nair, R., Acton, T.B., Rost, B., Montelione, G.T., Hunt, J.F., Tong, L., Northeast Structural Genomics Consortium (NESG)

Revision History

• Version 1.0: 2009-06-23
  Type: Initial release

• Version 1.1: 2011-07-13
  Changes: Version format compliance
• Version 1.2: 2017-11-01
  Changes: Refinement description
• Version 1.3: 2019-07-24
  Changes: Data collection, Derived calculations, Refinement description
