3HMZ | pdb_00003hmz

CRYSTAL STRUCTURE OF A FMN-BINDING DOMAIN OF FLAVIN REDUCTASES-LIKE ENZYME (SBAL_0626) FROM SHEWANELLA BALTICA OS155 AT 1.50 A RESOLUTION

PDB DOI: https://doi.org/10.2210/pdb3HMZ/pdb

Classification: OXIDOREDUCTASE
Organism(s): Shewanella baltica OS155
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2009-05-29 Released: 2009-06-30
Deposition Author(s): Joint Center for Structural Genomics (JCSG)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.50 Å
R-Value Free:
0.150 (Depositor), 0.161 (DCC)
R-Value Work:
0.129 (Depositor), 0.140 (DCC)
R-Value Observed:
0.130 (Depositor)

wwPDB Validation 3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.5 of the entry. See complete history.

Literature

Crystal structure of FMN-binding domain of flavin reductases-like enzyme (YP_001049024.1) from Shewanella baltica OS155 at 1.50 A resolution

Joint Center for Structural Genomics (JCSG)

To be published.

Macromolecule Content

Total Structure Weight: 23.07 kDa
Atom Count: 1,859
Modeled Residue Count: 191
Deposited Residue Count: 199
Unique protein chains: 1

Macromolecules

Find similar proteins by:

| 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Flavin reductase domain protein, FMN-binding	A	199	Shewanella baltica OS155	Mutation(s): 0 Gene Names: Sbal_0626, YP_001049024.1
UniProt
Find proteins for A3D092 (Shewanella baltica (strain OS155 / ATCC BAA-1091)) Explore A3D092 Go to UniProtKB: A3D092
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	A3D092
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 4 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
FMN Query on FMN Download:Ideal Coordinates CCD File SDF format, chain B [auth A] MOL2 format, chain B [auth A] mmCIF format, chain B [auth A]	B [auth A]	FLAVIN MONONUCLEOTIDE C₁₇ H₂₁ N₄ O₉ P FVTCRASFADXXNN-SCRDCRAPSA-N		Interactions Focus chain B [auth A] Interactions & Density Focus chain B [auth A]
IMD Query on IMD Download:Ideal Coordinates CCD File SDF format, chain D [auth A] MOL2 format, chain D [auth A] mmCIF format, chain D [auth A]	D [auth A]	IMIDAZOLE C₃ H₅ N₂ RAXXELZNTBOGNW-UHFFFAOYSA-O		Interactions Focus chain D [auth A] Interactions & Density Focus chain D [auth A]
EDO Query on EDO Download:Ideal Coordinates CCD File SDF format, chain E [auth A] SDF format, chain F [auth A] SDF format, chain G [auth A] SDF format, chain H [auth A] SDF format, chain I [auth A] SDF format, chain J [auth A] MOL2 format, chain E [auth A] MOL2 format, chain F [auth A] MOL2 format, chain G [auth A] MOL2 format, chain H [auth A] MOL2 format, chain I [auth A] MOL2 format, chain J [auth A] mmCIF format, chain E [auth A] mmCIF format, chain F [auth A] mmCIF format, chain G [auth A] mmCIF format, chain H [auth A] mmCIF format, chain I [auth A] mmCIF format, chain J [auth A]	E [auth A] F [auth A] G [auth A] H [auth A] I [auth A] E [auth A], F [auth A], G [auth A], H [auth A], I [auth A], J [auth A]	1,2-ETHANEDIOL C₂ H₆ O₂ LYCAIKOWRPUZTN-UHFFFAOYSA-N		Interactions Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Focus chain H [auth A] Focus chain I [auth A] Focus chain J [auth A] Interactions & Density Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Focus chain H [auth A] Focus chain I [auth A] Focus chain J [auth A]
UNL Query on UNL Download:Ideal Coordinates CCD File	C [auth A]	Unknown ligand LYCAIKOWRPUZTN-UHFFFAOYSA-N		Interactions Focus chain C [auth A] Interactions & Density Focus chain C [auth A]

Modified Residues 1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE Query on MSE	A	L-PEPTIDE LINKING	C₅ H₁₁ N O₂ Se		MET

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.50 Å
R-Value Free: 0.150 (Depositor), 0.161 (DCC)
R-Value Work: 0.129 (Depositor), 0.140 (DCC)
R-Value Observed: 0.130 (Depositor)

Diffraction Data:

Space Group: P 3₁ 2 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 74.627	α = 90
b = 74.627	β = 90
c = 74.107	γ = 120

Software Package:

Software Name	Purpose
REFMAC	refinement
PHENIX	refinement
SHELX	phasing
MolProbity	model building
XSCALE	data scaling
PDB_EXTRACT	data extraction
XDS	data reduction
SHELXD	phasing
autoSHARP	phasing

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2009-06-30

Deposition Author(s):

Joint Center for Structural Genomics (JCSG)

Revision History (Full details and data files)

Version 1.0: 2009-06-30
Type: Initial release
Version 1.1: 2011-07-13
Changes: Source and taxonomy, Version format compliance
Version 1.2: 2017-11-01
Changes: Refinement description
Version 1.3: 2019-07-24
Changes: Data collection, Derived calculations, Refinement description
Version 1.4: 2023-02-01
Changes: Database references, Derived calculations
Version 1.5: 2024-10-30
Changes: Data collection, Structure summary
