3HJV | pdb_00003hjv

1.7 Angstrom resolution crystal structure of an acyl carrier protein S-malonyltransferase from Vibrio cholerae O1 biovar eltor str. N16961

PDB DOI: https://doi.org/10.2210/pdb3HJV/pdb

Classification: TRANSFERASE
Organism(s): Vibrio cholerae
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2009-05-22 Released: 2009-06-09
Deposition Author(s): Halavaty, A.S., Wawrzak, Z., Anderson, S., Skarina, T., Onopriyenko, O., Kwon, K., Savchenko, A., Anderson, W.F., Center for Structural Genomics of Infectious Diseases (CSGID)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.70 Å
R-Value Free:
0.193 (Depositor), 0.194 (DCC)
R-Value Work:
0.145 (Depositor), 0.152 (DCC)
R-Value Observed:
0.148 (Depositor)

wwPDB Validation 3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.3 of the entry. See complete history.

Literature

1.7 Angstrom resolution crystal structure of an acyl carrier protein S-malonyltransferase from Vibrio cholerae O1 biovar eltor str. N16961

Halavaty, A.S., Wawrzak, Z., Anderson, S., Skarina, T., Onopriyenko, O., Kwon, K., Savchenko, A., Anderson, W.F., Center for Structural Genomics of Infectious Diseases (CSGID)

To be published.

Macromolecule Content

Total Structure Weight: 70.74 kDa
Atom Count: 5,917
Modeled Residue Count: 613
Deposited Residue Count: 624
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Malonyl Coa-acyl carrier protein transacylase	A, B	312	Vibrio cholerae	Mutation(s): 0 Gene Names: VC_2022 EC: 2.3.1.39
UniProt
Find proteins for Q9KQH6 (Vibrio cholerae serotype O1 (strain ATCC 39315 / El Tor Inaba N16961)) Explore Q9KQH6 Go to UniProtKB: Q9KQH6
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	Q9KQH6
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 4 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
CXS Query on CXS Download Ideal Coordinates CCD File SDF format, chain EA [auth B] SDF format, chain FA [auth B] SDF format, chain N [auth A] SDF format, chain O [auth A] SDF format, chain P [auth A] SDF format, chain Q [auth A] MOL2 format, chain EA [auth B] MOL2 format, chain FA [auth B] MOL2 format, chain N [auth A] MOL2 format, chain O [auth A] MOL2 format, chain P [auth A] MOL2 format, chain Q [auth A] mmCIF format, chain EA [auth B] mmCIF format, chain FA [auth B] mmCIF format, chain N [auth A] mmCIF format, chain O [auth A] mmCIF format, chain P [auth A] mmCIF format, chain Q [auth A]	EA [auth B] FA [auth B] N [auth A] O [auth A] P [auth A] EA [auth B], FA [auth B], N [auth A], O [auth A], P [auth A], Q [auth A]	3-CYCLOHEXYL-1-PROPYLSULFONIC ACID C₉ H₁₉ N O₃ S PJWWRFATQTVXHA-UHFFFAOYSA-N		Interactions Focus chain EA [auth B] Focus chain FA [auth B] Focus chain N [auth A] Focus chain O [auth A] Focus chain P [auth A] Focus chain Q [auth A] Interactions & Density Focus chain EA [auth B] Focus chain FA [auth B] Focus chain N [auth A] Focus chain O [auth A] Focus chain P [auth A] Focus chain Q [auth A]
8JZ Query on 8JZ Download Ideal Coordinates CCD File SDF format, chain W [auth A] MOL2 format, chain W [auth A] mmCIF format, chain W [auth A]	W [auth A]	butyl acetate C₆ H₁₂ O₂ DKPFZGUDAPQIHT-UHFFFAOYSA-N		Interactions Focus chain W [auth A] Interactions & Density Focus chain W [auth A]
SO4 Query on SO4 Download Ideal Coordinates CCD File SDF format, chain AA [auth B] SDF format, chain BA [auth B] SDF format, chain C [auth A] SDF format, chain CA [auth B] SDF format, chain D [auth A] SDF format, chain DA [auth B] SDF format, chain E [auth A] SDF format, chain F [auth A] SDF format, chain G [auth A] SDF format, chain H [auth A] SDF format, chain I [auth A] SDF format, chain J [auth A] SDF format, chain K [auth A] SDF format, chain L [auth A] SDF format, chain M [auth A] SDF format, chain X [auth B] SDF format, chain Y [auth B] SDF format, chain Z [auth B] MOL2 format, chain AA [auth B] MOL2 format, chain BA [auth B] MOL2 format, chain C [auth A] MOL2 format, chain CA [auth B] MOL2 format, chain D [auth A] MOL2 format, chain DA [auth B] MOL2 format, chain E [auth A] MOL2 format, chain F [auth A] MOL2 format, chain G [auth A] MOL2 format, chain H [auth A] MOL2 format, chain I [auth A] MOL2 format, chain J [auth A] MOL2 format, chain K [auth A] MOL2 format, chain L [auth A] MOL2 format, chain M [auth A] MOL2 format, chain X [auth B] MOL2 format, chain Y [auth B] MOL2 format, chain Z [auth B] mmCIF format, chain AA [auth B] mmCIF format, chain BA [auth B] mmCIF format, chain C [auth A] mmCIF format, chain CA [auth B] mmCIF format, chain D [auth A] mmCIF format, chain DA [auth B] mmCIF format, chain E [auth A] mmCIF format, chain F [auth A] mmCIF format, chain G [auth A] mmCIF format, chain H [auth A] mmCIF format, chain I [auth A] mmCIF format, chain J [auth A] mmCIF format, chain K [auth A] mmCIF format, chain L [auth A] mmCIF format, chain M [auth A] mmCIF format, chain X [auth B] mmCIF format, chain Y [auth B] mmCIF format, chain Z [auth B]	AA [auth B] BA [auth B] C [auth A] CA [auth B] D [auth A] AA [auth B], BA [auth B], C [auth A], CA [auth B], D [auth A], DA [auth B], E [auth A], F [auth A], G [auth A], H [auth A], I [auth A], J [auth A], K [auth A], L [auth A], M [auth A], X [auth B], Y [auth B], Z [auth B]	SULFATE ION O₄ S QAOWNCQODCNURD-UHFFFAOYSA-L		Interactions Focus chain AA [auth B] Focus chain BA [auth B] Focus chain C [auth A] Focus chain CA [auth B] Focus chain D [auth A] Focus chain DA [auth B] Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Focus chain H [auth A] Focus chain I [auth A] Focus chain J [auth A] Focus chain K [auth A] Focus chain L [auth A] Focus chain M [auth A] Focus chain X [auth B] Focus chain Y [auth B] Focus chain Z [auth B] Interactions & Density Focus chain AA [auth B] Focus chain BA [auth B] Focus chain C [auth A] Focus chain CA [auth B] Focus chain D [auth A] Focus chain DA [auth B] Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Focus chain H [auth A] Focus chain I [auth A] Focus chain J [auth A] Focus chain K [auth A] Focus chain L [auth A] Focus chain M [auth A] Focus chain X [auth B] Focus chain Y [auth B] Focus chain Z [auth B]
CL Query on CL Download Ideal Coordinates CCD File SDF format, chain GA [auth B] SDF format, chain HA [auth B] SDF format, chain IA [auth B] SDF format, chain JA [auth B] SDF format, chain R [auth A] SDF format, chain S [auth A] SDF format, chain T [auth A] SDF format, chain U [auth A] SDF format, chain V [auth A] MOL2 format, chain GA [auth B] MOL2 format, chain HA [auth B] MOL2 format, chain IA [auth B] MOL2 format, chain JA [auth B] MOL2 format, chain R [auth A] MOL2 format, chain S [auth A] MOL2 format, chain T [auth A] MOL2 format, chain U [auth A] MOL2 format, chain V [auth A] mmCIF format, chain GA [auth B] mmCIF format, chain HA [auth B] mmCIF format, chain IA [auth B] mmCIF format, chain JA [auth B] mmCIF format, chain R [auth A] mmCIF format, chain S [auth A] mmCIF format, chain T [auth A] mmCIF format, chain U [auth A] mmCIF format, chain V [auth A]	GA [auth B] HA [auth B] IA [auth B] JA [auth B] R [auth A] GA [auth B], HA [auth B], IA [auth B], JA [auth B], R [auth A], S [auth A], T [auth A], U [auth A], V [auth A]	CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M		Interactions Focus chain GA [auth B] Focus chain HA [auth B] Focus chain IA [auth B] Focus chain JA [auth B] Focus chain R [auth A] Focus chain S [auth A] Focus chain T [auth A] Focus chain U [auth A] Focus chain V [auth A] Interactions & Density Focus chain GA [auth B] Focus chain HA [auth B] Focus chain IA [auth B] Focus chain JA [auth B] Focus chain R [auth A] Focus chain S [auth A] Focus chain T [auth A] Focus chain U [auth A] Focus chain V [auth A]

Modified Residues 1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE Query on MSE	A, B	L-PEPTIDE LINKING	C₅ H₁₁ N O₂ Se		MET

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.70 Å
R-Value Free: 0.193 (Depositor), 0.194 (DCC)
R-Value Work: 0.145 (Depositor), 0.152 (DCC)
R-Value Observed: 0.148 (Depositor)

Diffraction Data: https://doi.org/10.18430/m33hjv

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 46.525	α = 90
b = 87.789	β = 90
c = 121.957	γ = 90

Software Package:

Software Name	Purpose
Blu-Ice	data collection
REFMAC	refinement
HKL-2000	data reduction
XDS	data reduction
HKL-2000	data scaling
XSCALE	data scaling
SHELXCD	phasing
SHELXD	phasing
SHELXE	model building
Bp3	phasing
SOLOMON	phasing
ARP/wARP	model building

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

Entry History

Deposition Data

Released Date: 2009-06-09

Deposition Author(s):

Center for Structural Genomics of Infectious Diseases (CSGID)

Revision History (Full details and data files)

Version 1.0: 2009-06-09
Type: Initial release
Version 1.1: 2011-07-13
Changes: Advisory, Version format compliance
Version 1.2: 2017-11-01
Changes: Refinement description
Version 1.3: 2024-10-30
Changes: Data collection, Database references, Derived calculations, Structure summary
