3HFI | pdb_00003hfi

The crystal structure of the putative regulator from Escherichia coli CFT073

PDB DOI: https://doi.org/10.2210/pdb3HFI/pdb

Classification: structural genomics, unknown function
Organism(s): Escherichia coli O6
Expression System: Escherichia coli BL21
Mutation(s): No

Deposited: 2009-05-11 Released: 2009-05-26
Deposition Author(s): Zhang, R., Xu, X., Zheng, H., Savchenko, A., Edwards, A., Joachimiak, A., Midwest Center for Structural Genomics (MCSG)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.20 Å
R-Value Free:
0.256 (Depositor), 0.275 (DCC)
R-Value Work:
0.201 (Depositor), 0.225 (DCC)
R-Value Observed:
0.203 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 3HFI

This is version 1.2 of the entry. See complete history.

Literature

The crystal structure of the putative regulator from Escherichia coli CFT073

Zhang, R., Xu, X., Zheng, H., Savchenko, A., Edwards, A., Joachimiak, A.

To be published.

Macromolecule Content

Total Structure Weight: 19.66 kDa
Atom Count: 1,146
Modeled Residue Count: 137
Deposited Residue Count: 170
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Putative regulator	A	170	Escherichia coli O6	Mutation(s): 0 Gene Names: c4276, GI:26250098
UniProt
Find proteins for A0A0H2VBL3 (Escherichia coli O6:H1 (strain CFT073 / ATCC 700928 / UPEC)) Explore A0A0H2VBL3 Go to UniProtKB: A0A0H2VBL3
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	A0A0H2VBL3
Sequence Annotations Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.20 Å
R-Value Free: 0.256 (Depositor), 0.275 (DCC)
R-Value Work: 0.201 (Depositor), 0.225 (DCC)
R-Value Observed: 0.203 (Depositor)

Space Group: P 6₃ 2 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 103.656	α = 90
b = 103.656	β = 90
c = 58.209	γ = 120

Software Package:

Software Name	Purpose
SBC-Collect	data collection
HKL-3000	phasing
REFMAC	refinement
HKL-3000	data reduction
HKL-3000	data scaling

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2009-05-26

Deposition Author(s):

Midwest Center for Structural Genomics (MCSG)

Revision History (Full details and data files)

Version 1.0: 2009-05-26
Type: Initial release
Version 1.1: 2011-07-13
Changes: Advisory, Version format compliance
Version 1.2: 2024-02-21
Changes: Data collection, Database references
