3H3P

Crystal structure of HIV epitope-scaffold 4E10 Fv complex


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.70 Å
  • R-Value Free: 0.287
  • R-Value Work: 0.229
  • R-Value Observed: 0.232

wwPDB Validation   3D Report Full Report


This is version 1.1 of the entry. See complete history


Literature

Interactions between lipids and human anti-HIV antibody 4E10 can be reduced without ablating neutralizing activity

Xu, H.Song, L.Kim, M.Holmes, M.A.Kraft, Z.Sellhorn, G.Reinherz, E.L.Stamatatos, L.Strong, R.K.

(2010) J Virol 84: 1076-1088

  • DOI: 10.1128/JVI.02113-09
  • Primary Citation of Related Structures:
    3H3P

  • PubMed Abstract:
  • Human 4E10 is one of the broadest-specificity, HIV-1-neutralizing monoclonal antibodies known, recognizing a membrane-proximal linear epitope on gp41. The lipid cross-reactivity of 4E10 has been alternately suggested either to contribute to the apparent rarity of 4E10-like antibody responses in HIV infections, through elimination by B-cell tolerance mechanisms to self-antigens, or to contribute to neutralization potency by virus-specific membrane binding outside of the membrane-proximal external region (MPER) ...

    Human 4E10 is one of the broadest-specificity, HIV-1-neutralizing monoclonal antibodies known, recognizing a membrane-proximal linear epitope on gp41. The lipid cross-reactivity of 4E10 has been alternately suggested either to contribute to the apparent rarity of 4E10-like antibody responses in HIV infections, through elimination by B-cell tolerance mechanisms to self-antigens, or to contribute to neutralization potency by virus-specific membrane binding outside of the membrane-proximal external region (MPER). To investigate how 4E10 interacts with membrane and protein components, and whether such interactions contribute to neutralization mechanisms, we introduced two mutations into 4E10 Fv constructs, Trp to Ala at position 100 in the heavy chain [W(H100)A] and Gly to Glu at position 50 in the light chain [G(L50)E], selected to disrupt potential lipid interactions via different mechanisms. Wild-type and mutant Fvs all bound with the same affinity to peptides and monomeric and trimeric gp140s, but the affinities for gp140s were uniformly 10-fold weaker than to peptides. 4E10 Fv binding responses to liposomes in the presence or absence of MPER peptides were weak in absolute terms, consistent with prior observations, and both mutations attenuated interactions even further, as predicted. The W(H100)A mutation reduced neutralization efficiency against four HIV-1 isolates, but the G(L50)E mutation increased potency across the same panel. Electron paramagnetic resonance experiments showed that the W(H100)A mutation, but not the G(L50)E mutation, reduced the ability of 4E10 to extract MPER peptides from membranes. These results show that 4E10 nonspecific membrane binding is separable from neutralization, which is achieved through specific peptide/lipid orientation changes.


    Organizational Affiliation

    Division of Basic Sciences, Fred Hutchinson Cancer Research Center, 1100 Fairview Ave. N., Seattle, WA 98109, USA.



Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
Fv 4E10 heavy chainA [auth H],
B [auth I]
137Homo sapiensMutation(s): 0
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChainsSequence LengthOrganismDetailsImage
Fv 4E10 light chainC [auth L],
D [auth M]
114Homo sapiensMutation(s): 0
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 3
MoleculeChainsSequence LengthOrganismDetailsImage
4E10_S0_1TJLC_004_NE [auth S],
F [auth T]
85synthetic constructMutation(s): 0
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
Protein Feature View
Expand
  • Reference Sequence
Small Molecules
Ligands 1 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
CA
Query on CA

Download Ideal Coordinates CCD File
G [auth H]CALCIUM ION
Ca
BHPQYMZQTOCNFJ-UHFFFAOYSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.70 Å
  • R-Value Free: 0.287
  • R-Value Work: 0.229
  • R-Value Observed: 0.232
  • Space Group: P 65 2 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 92.4α = 90
b = 92.4β = 90
c = 272.79γ = 120
Software Package:
Software NamePurpose
CrystalCleardata collection
PHASERphasing
REFMACrefinement
d*TREKdata reduction
d*TREKdata scaling

Structure Validation

View Full Validation Report




Entry History

Deposition Data

  • Deposited Date: 2009-04-16
  • Released Date: 2010-01-19
  • Deposition Author(s): Holmes, M.A.

Revision History  (Full details and data files)

  • Version 1.0: 2010-01-19
    Type: Initial release
  • Version 1.1: 2011-07-13
    Changes: Advisory, Version format compliance
