Crystal structure of a bacteria TIR domain, PdTIR from Paracoccus denitrificans

Experimental Data Snapshot

  • Resolution: 2.50 Å
  • R-Value Free: 0.243
  • R-Value Work: 0.192
  • R-Value Observed: 0.192

wwPDB Validation   3D Report Full Report

This is version 1.3 of the entry. See complete history


Molecular Mimicry in Innate Immunity: CRYSTAL STRUCTURE OF A BACTERIAL TIR DOMAIN.

Chan, S.L.Low, L.Y.Hsu, S.Li, S.Liu, T.Santelli, E.Le Negrate, G.Reed, J.C.Woods, V.L.Pascual, J.

(2009) J Biol Chem 284: 21386-21392

  • DOI: https://doi.org/10.1074/jbc.C109.007591
  • Primary Citation of Related Structures:

  • PubMed Abstract:

    Macrophages detect pathogen infection via the activation of their plasma membrane-bound Toll-like receptor proteins (TLRs). The heterotypic interaction between the Toll/interleukin-1 receptor (TIR) domains of TLRs and adaptor proteins, like Myeloid differentiation primary response gene 88 (MyD88), is the first intracellular step in the signaling pathway of the mammalian innate immune response. The hetero-oligomerization of the TIRs of the receptor and adaptor brings about the activation of the transcription factor NF-kappaB, which regulates the synthesis of pro-inflammatory cytokines. Here, we report the first crystal structure of a bacterial TIR domain solved at 2.5 A resolution. The three-dimensional fold of Paracoccus denitrificans TIR is identical to that observed for the TIR of human TLRs and MyD88 proteins. The structure shows a unique dimerization interface involving the DD-loop and EE-loop residues, whereas leaving the BB-loop highly exposed. Peptide amide hydrogen-deuterium exchange mass spectrometry also reveals that the same region is used for dimerization in solution and in the context of the full-length protein. These results, together with a functional interaction between P. denitrificans TIR and MyD88 visualized in a co-immunoprecipitation assay, further substantiate the model that bacterial TIR proteins adopt structural mimicry of the host active receptor TIR domains to interfere with the signaling of TLRs and their adaptors to decrease the inflammatory response.

  • Organizational Affiliation

    Inflammation and Infectious Diseases Center and Cancer Center, Burnham Institute for Medical Research, La Jolla, California 92037, USA.

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
TIR protein
A, B, C, D
154Paracoccus denitrificans PD1222Mutation(s): 0
Gene Names: Pden_0113PdTLP
Find proteins for A1AY86 (Paracoccus denitrificans (strain Pd 1222))
Explore A1AY86
Go to UniProtKB:  A1AY86
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA1AY86
Sequence Annotations
  • Reference Sequence
Small Molecules
Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
Query on SO4

Download Ideal Coordinates CCD File
O4 S
Experimental Data & Validation

Experimental Data

  • Resolution: 2.50 Å
  • R-Value Free: 0.243
  • R-Value Work: 0.192
  • R-Value Observed: 0.192
  • Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 80.78α = 90
b = 85.61β = 90
c = 89.62γ = 90
Software Package:
Software NamePurpose
DENZOdata reduction
SCALEPACKdata scaling
PDB_EXTRACTdata extraction
HKL-2000data collection

Structure Validation

View Full Validation Report

Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2009-06-16
    Type: Initial release
  • Version 1.1: 2011-07-13
    Changes: Version format compliance
  • Version 1.2: 2017-11-01
    Changes: Refinement description
  • Version 1.3: 2024-02-21
    Changes: Data collection, Database references, Derived calculations
