3GWJ

Crystal structure of Antheraea pernyi arylphorin

Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.43 Å
  • R-Value Free: 0.229
  • R-Value Work: 0.182
  • R-Value Observed: 0.182

wwPDB Validation   3D Report Full Report


This is version 2.0 of the entry. See complete history.


Literature

The presence of monoglucosylated N196-glycan is important for the structural stability of storage protein, arylphorin

Ryu, K.S., Lee, J.O., Kwon, T.H., Choi, H.H., Park, H.S., Hwang, S.K., Lee, Z.W., Lee, K.B., Han, Y.H., Choi, Y.S., Jeon, Y.H., Cheong, C., Kim, S.

(2009) Biochem J 421: 87-96

  • DOI: 10.1042/BJ20082170
  • Primary Citation of Related Structures:
    3GWJ

  • PubMed Abstract:

    • Although N-glycosylation has been known to increase the stability of glycoproteins, it is difficult to assess the structural importance of glycans in the stabilization of glycoproteins. APA (Antheraea pernyi arylphorin) is an insect hexamerin that has two N-glycosylations at Asn196 and Asn344 respectively ...

    Although N-glycosylation has been known to increase the stability of glycoproteins, it is difficult to assess the structural importance of glycans in the stabilization of glycoproteins. APA (Antheraea pernyi arylphorin) is an insect hexamerin that has two N-glycosylations at Asn196 and Asn344 respectively. The glycosylation of Asn344 is critical for the folding process; however, glycosylation of Asn196 is not. Interestingly, the N196-glycan (glycosylation of Asn196) remains in an immature form (Glc1Man9GlcNAc2). The mutation of Asn196 to glutamine does not change the ecdysone-binding activity relative to that of the wild-type. In the present study, we determined the crystal structure of APA, and all sugar moieties of the N196-glycan were clearly observed in the electron-density map. Although the sugar moieties of the glycan generally have high structural flexibility, most sugar moieties of the N196-glycan were well organized in the deep cleft of the subunit interface and mediated many inter- and intrasubunit hydrogen bonds. Analytical ultracentrifugation and GdmCl (guanidinium chloride) unfolding experiments revealed that the presence of the N196-glycan was important for stabilizing the hexameric state and overall stability of APA respectively. Our results could provide a structural basis for studying not only other glycoproteins that carry an immature N-glycan, but also the structural role of N-glycans that are located in the deep cleft of a protein.

    Organizational Affiliation:

    Magnetic Resonance Team, Korea Basic Science Institute, Gwahangno 113, Daejeon 305-333, South Korea.



Macromolecules
Find similar proteins by:
(by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
Arylphorin
A, B, C, D, E, F
A, B, C, D, E, F
674Antheraea pernyiMutation(s): 0
UniProt
Find proteins for Q7Z1F8 (Antheraea pernyi)
Explore Q7Z1F8
Go to UniProtKB:  Q7Z1F8
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ7Z1F8
Protein Feature View
Expand
  • Reference Sequence
Oligosaccharides

Help

Entity ID: 2
MoleculeChainsChain Length2D DiagramGlycosylation3D Interactions
alpha-D-glucopyranose-(1-3)-alpha-D-mannopyranose-(1-2)-alpha-D-mannopyranose-(1-2)-alpha-D-mannopyranose-(1-3)-[alpha-D-mannopyranose-(1-2)-alpha-D-mannopyranose-(1-3)-[alpha-D-mannopyranose-(1-2)-alpha-D-mannopyranose-(1-6)]alpha-D-mannopyranose-(1-6)]beta-D-mannopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose
G, I, K, M, O, Q
G, I, K, M, O, Q
12N-Glycosylation Oligosaccharides Interaction
Glycosylation Resources
GlyTouCan:  G19958IL
GlyCosmos:  G19958IL
GlyGen:  G19958IL
Entity ID: 3
MoleculeChainsChain Length2D DiagramGlycosylation3D Interactions
2-acetamido-2-deoxy-beta-D-glucopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose
H, J, L, N, P, R
H, J, L, N, P, R
2N-Glycosylation Oligosaccharides Interaction
Glycosylation Resources
GlyTouCan:  G42666HT
GlyCosmos:  G42666HT
GlyGen:  G42666HT
Small Molecules
Ligands 1 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
FMT
Query on FMT
Download Ideal Coordinates CCD File
S [auth A],
T [auth B],
U [auth C],
V [auth D],
W [auth E],
S [auth A],
T [auth B],
U [auth C],
V [auth D],
W [auth E],
X [auth F]
FORMIC ACID
C H2 O2
BDAGIHXWWSANSR-UHFFFAOYSA-N		 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.43 Å
  • R-Value Free: 0.229
  • R-Value Work: 0.182
  • R-Value Observed: 0.182
  • Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 121.196α = 90
b = 119.47β = 90
c = 319.878γ = 90
Software Package:
Software NamePurpose
HKL-2000data collection
CNSrefinement
HKL-2000data reduction
HKL-2000data scaling
CNSphasing

Structure Validation

View Full Validation Report



View more in-depth experimental data

Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2009-05-05
    Type: Initial release
  • Version 1.1: 2011-07-13
    Changes: Non-polymer description, Version format compliance
  • Version 2.0: 2020-07-29
    Type: Remediation
    Reason: Carbohydrate remediation
    Changes: Atomic model, Data collection, Derived calculations, Structure summary
