Pyrococcus Horikoshii NOP5 RNA Binding Domain

Experimental Data Snapshot

  • Resolution: 2.50 Å
  • R-Value Free: 0.334
  • R-Value Work: 0.299
  • R-Value Observed: 0.302

wwPDB Validation   3D Report Full Report

This is version 1.3 of the entry. See complete history


Analysis of a Critical Interaction within the Archaeal Box C/D Small Ribonucleoprotein Complex

Hardin, J.W.Reyes, F.E.Batey, R.T.

(2009) J Biol Chem 284: 15317-15324

  • DOI: https://doi.org/10.1074/jbc.M901368200
  • Primary Citation of Related Structures:
    3GQU, 3GQX

  • PubMed Abstract:

    In archaea and eukarya, box C/D ribonucleoprotein (RNP) complexes are responsible for 2'-O-methylation of tRNAs and rRNAs. The archaeal box C/D small RNP complex requires a small RNA component (sRNA) possessing Watson-Crick complementarity to the target RNA along with three proteins: L7Ae, Nop5p, and fibrillarin. Transfer of a methyl group from S-adenosylmethionine to the target RNA is performed by fibrillarin, which by itself has no affinity for the sRNA-target duplex. Instead, it is targeted to the site of methylation through association with Nop5p, which in turn binds to the L7Ae-sRNA complex. To understand how Nop5p serves as a bridge between the targeting and catalytic functions of the box C/D small RNP complex, we have employed alanine scanning to evaluate the interaction between the Pyrococcus horikoshii Nop5p domain and an L7Ae box C/D RNA complex. From these data, we were able to construct an isolated RNA-binding domain (Nop-RBD) that folds correctly as demonstrated by x-ray crystallography and binds to the L7Ae box C/D RNA complex with near wild type affinity. These data demonstrate that the Nop-RBD is an autonomously folding and functional module important for protein assembly in a number of complexes centered on the L7Ae-kinkturn RNP.

  • Organizational Affiliation

    Department of Chemistry and Biochemistry, University of Colorado, Boulder, Colorado 80309-0215, USA.

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
NOP5P PROTEIN169Pyrococcus horikoshiiMutation(s): 0
Gene Names: NOP5PPH0053
Find proteins for O57810 (Pyrococcus horikoshii (strain ATCC 700860 / DSM 12428 / JCM 9974 / NBRC 100139 / OT-3))
Explore O57810
Go to UniProtKB:  O57810
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupO57810
Sequence Annotations
  • Reference Sequence
Small Molecules
Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
Query on IOD

Download Ideal Coordinates CCD File
B [auth A]
C [auth A]
D [auth A]
E [auth A]
F [auth A]
B [auth A],
C [auth A],
D [auth A],
E [auth A],
F [auth A],
G [auth A],
H [auth A],
I [auth A],
J [auth A],
K [auth A],
L [auth A],
M [auth A]
Experimental Data & Validation

Experimental Data

  • Resolution: 2.50 Å
  • R-Value Free: 0.334
  • R-Value Work: 0.299
  • R-Value Observed: 0.302
  • Space Group: P 41 21 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 73.604α = 90
b = 73.604β = 90
c = 114.279γ = 90
Software Package:
Software NamePurpose
MOSFLMdata reduction
SCALAdata scaling
PDB_EXTRACTdata extraction

Structure Validation

View Full Validation Report

Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2009-04-21
    Type: Initial release
  • Version 1.1: 2011-07-13
    Changes: Version format compliance
  • Version 1.2: 2017-07-26
    Changes: Data collection, Refinement description, Source and taxonomy
  • Version 1.3: 2024-02-21
    Changes: Data collection, Database references, Derived calculations
