3GQG

Crystal structure at acidic pH of the ferric form of the Root effect hemoglobin from Trematomus bernacchii.


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.73 Å
  • R-Value Free: 0.197
  • R-Value Work: 0.152

wwPDB Validation 3D Report Full Report


This is version 1.1 of the entry. See complete history

Literature

Correlation between hemichrome stability and the root effect in tetrameric hemoglobins.

Vergara, A.Franzese, M.Merlino, A.Bonomi, G.Verde, C.Giordano, D.di Prisco, G.Lee, H.C.Peisach, J.Mazzarella, L.

(2009) Biophys.J. 97: 866-874

  • DOI: 10.1016/j.bpj.2009.04.056

  • PubMed Abstract:
  • Oxidation of Hbs leads to the formation of different forms of Fe(III) that are relevant to a range of biochemical and physiological functions. Here we report a combined EPR/x-ray crystallography study performed at acidic pH on six ferric tetrameric H ...

    Oxidation of Hbs leads to the formation of different forms of Fe(III) that are relevant to a range of biochemical and physiological functions. Here we report a combined EPR/x-ray crystallography study performed at acidic pH on six ferric tetrameric Hbs. Five of the Hbs were isolated from the high-Antarctic notothenioid fishes Trematomus bernacchii, Trematomus newnesi, and Gymnodraco acuticeps, and one was isolated from the sub-Antarctic notothenioid Cottoperca gobio. Our EPR analysis reveals that 1), in all of these Hbs, at acidic pH the aquomet form and two hemichromes coexist; and 2), only in the three Hbs that exhibit the Root effect is a significant amount of the pentacoordinate (5C) high-spin Fe(III) form found. The crystal structure at acidic pH of the ferric form of the Root-effect Hb from T. bernacchii is also reported at 1.7 A resolution. This structure reveals a 5C state of the heme iron for both the alpha- and beta-chains within a T quaternary structure. Altogether, the spectroscopic and crystallographic results indicate that the Root effect and hemichrome stability at acidic pH are correlated in tetrameric Hbs. Furthermore, Antarctic fish Hbs exhibit higher peroxidase activity than mammalian and temperate fish Hbs, suggesting that a partial hemichrome state in tetrameric Hbs, unlike in monomeric Hbs, does not remove the need for protection from peroxide attack, in contrast to previous results from monomeric Hbs.


    Organizational Affiliation

    Department of Chemistry, University of Naples Federico II, Complesso Universitario Monte S. Angelo, Naples, Italy.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
Hemoglobin subunit alpha
A, C
143Pseudotrematomus bernacchiiMutation(s): 0
Gene Names: hba
Find proteins for P80043 (Pseudotrematomus bernacchii)
Go to UniProtKB:  P80043
Entity ID: 2
MoleculeChainsSequence LengthOrganismDetails
Hemoglobin subunit beta
B, D
146Pseudotrematomus bernacchiiMutation(s): 0
Gene Names: hbb
Find proteins for P80044 (Pseudotrematomus bernacchii)
Go to UniProtKB:  P80044
Small Molecules
Ligands 1 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
HEM
Query on HEM

Download SDF File
Download CCD File
A, B, C, D
PROTOPORPHYRIN IX CONTAINING FE
HEME
C34 H32 Fe N4 O4
KABFMIBPWCXCRK-RGGAHWMASA-L
 Ligand Interaction
Modified Residues  1 Unique
IDChainsTypeFormula2D DiagramParent
ACE
Query on ACE
A, C
NON-POLYMERC2 H4 O

--

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.73 Å
  • R-Value Free: 0.197
  • R-Value Work: 0.152
  • Space Group: P 1 21 1
Unit Cell:
Length (Å)Angle (°)
a = 61.720α = 90.00
b = 94.780β = 90.09
c = 61.720γ = 90.00
Software Package:
Software NamePurpose
SHELXL-97refinement
HKL-2000data reduction
AMoREphasing
HKL-2000data collection
HKL-2000data scaling

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2009-10-13
    Type: Initial release
  • Version 1.1: 2011-07-13
    Type: Version format compliance
