3GH1 | pdb_00003gh1

Crystal structure of predicted nucleotide-binding protein from Vibrio cholerae

• PDB DOI: https://doi.org/10.2210/pdb3GH1/pdb

• Classification: STRUCTURAL GENOMICS, UNKNOWN FUNCTION
• Organism(s): Vibrio cholerae O1 biovar El Tor str. N16961
• Expression System: Escherichia coli
• Mutation(s): No


• Deposited: 2009-03-02 Released: 2009-03-10
• Deposition Author(s): Malashkevich, V.N., Toro, R., Wasserman, S., Sauder, J.M., Burley, S.K., Almo, S.C., New York SGX Research Center for Structural Genomics (NYSGXRC)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.90 Å
• R-Value Free:
  0.226 (Depositor), 0.230 (DCC)
• R-Value Work:
  0.169 (Depositor), 0.170 (DCC)
• R-Value Observed:
  0.172 (Depositor)

Starting Model: experimental

Literature

Crystal structure of predicted nucleotide-binding protein from Vibrio cholerae.

Malashkevich, V.N., Toro, R., Wasserman, S., Sauder, J.M., Burley, S.K., Almo, S.C.

To be published.

Biological Assembly 1

Global Symmetry: Dihedral - D2  (Explore in 3D)
Global Stoichiometry: Homo 4-mer - A4

Biological assembly 1 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 210.64 kDa
• Atom Count: 15,320
• Modeled Residue Count: 1,779
• Deposited Residue Count: 1,848
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Predicted nucleotide-binding protein	A, B, C, D	462	Vibrio cholerae O1 biovar El Tor str. N16961	Mutation(s): 0  Gene Names: VC_0899 EC: 3.2.2.10 (UniProt), 3.2.2.4 (UniProt)
UniProt
Find proteins for Q9KTK3 (Vibrio cholerae serotype O1 (strain ATCC 39315 / El Tor Inaba N16961)) Explore Q9KTK3  Go to UniProtKB:  Q9KTK3

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
PO4	E [auth A], F [auth B], G [auth C], H [auth D]	PHOSPHATE ION O4 P NBIIXXVUZAFLBC-UHFFFAOYSA-K

Modified Residues  1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE	A, B, C, D	L-PEPTIDE LINKING	C5 H11 N O2 Se		MET

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.90 Å
• R-Value Free:  0.226 (Depositor), 0.230 (DCC)
• R-Value Work:  0.169 (Depositor), 0.170 (DCC)
• R-Value Observed: 0.172 (Depositor)

Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 59.034	α = 90
b = 181.546	β = 103.32
c = 95.772	γ = 90

Software Package:

Software Name	Purpose
SCALA	data scaling
PHASER	phasing
REFMAC	refinement
PDB_EXTRACT	data extraction
MAR345	data collection
MOSFLM	data reduction

Structure Validation

Entry History

Deposition Data

• Released Date: 2009-03-10
Deposition Author(s): Malashkevich, V.N., Toro, R., Wasserman, S., Sauder, J.M., Burley, S.K., Almo, S.C., New York SGX Research Center for Structural Genomics (NYSGXRC)

Revision History

• Version 1.0: 2009-03-10
  Type: Initial release

• Version 1.1: 2011-07-13
  Changes: Advisory, Refinement description, Version format compliance
• Version 1.2: 2017-11-01
  Changes: Refinement description
• Version 1.3: 2018-11-21
  Changes: Data collection, Structure summary
• Version 1.4: 2021-02-10
  Changes: Database references, Derived calculations, Structure summary
• Version 1.5: 2023-09-06
  Changes: Data collection, Database references, Refinement description
• Version 1.6: 2023-11-22
  Changes: Data collection
• Version 1.7: 2024-10-16
  Changes: Structure summary
