3FV6

Crystal Structure of the CBS domains from the Bacillus subtilis CcpN repressor

PDB DOI: https://doi.org/10.2210/pdb3FV6/pdb

Classification: TRANSCRIPTION
Organism(s): Bacillus subtilis
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2009-01-15 Released: 2010-01-26
Deposition Author(s): Chaix, D., Arold, S., Hoh, F., Declerck, N.

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.95 Å
R-Value Free: 0.272
R-Value Work: 0.200
R-Value Observed: 0.202

wwPDB Validation 3D Report Full Report

This is version 1.2 of the entry. See complete history.

Literature

Ligand recognition by the energy sensor domain of the CcpN repressor

Chaix, D., de Guillen, K., Coq, D.L., Hoh, F., Roumestand, C., Aymerich, S., Arold, S.T., Declerck, N.

To be published.

Macromolecule Content

Total Structure Weight: 36.03 kDa
Atom Count: 2,425
Modelled Residue Count: 291
Deposited Residue Count: 318
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
YqzB protein	A, B	159	Bacillus subtilis	Mutation(s): 0 Gene Names: yqzB
UniProt
Find proteins for O34994 (Bacillus subtilis (strain 168)) Explore O34994 Go to UniProtKB: O34994
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	O34994
Sequence Annotations Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.95 Å
R-Value Free: 0.272
R-Value Work: 0.200
R-Value Observed: 0.202
Space Group: C 2 2 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 54.751	α = 90
b = 104.052	β = 90
c = 99.523	γ = 90

Software Package:

Software Name	Purpose
SOLVE	phasing
REFMAC	refinement
MOSFLM	data reduction
SCALA	data scaling

Structure Validation

View Full Validation Report

Entry History

Deposition Data

Released Date: 2010-01-26

Deposition Author(s):

Revision History (Full details and data files)

Version 1.0: 2010-01-26
Type: Initial release
Version 1.1: 2011-07-13
Changes: Advisory, Version format compliance
Version 1.2: 2024-03-20
Changes: Data collection, Database references
