3CTZ

Structure of human cytosolic X-prolyl aminopeptidase


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.60 Å
  • R-Value Free: 0.196
  • R-Value Work: 0.154
  • R-Value Observed: 0.156

wwPDB Validation   3D Report Full Report


This is version 1.2 of the entry. See complete history


Literature

Structure of human cytosolic X-prolyl aminopeptidase: a double Mn(II)-dependent dimeric enzyme with a novel three-domain subunit

Li, X.Lou, Z.Li, X.Zhou, W.Ma, M.Cao, Y.Geng, Y.Bartlam, M.Zhang, X.C.Rao, Z.

(2008) J Biol Chem 283: 22858-22866

  • DOI: https://doi.org/10.1074/jbc.M710274200
  • Primary Citation of Related Structures:
    3CTZ

  • PubMed Abstract:
  • X-prolyl aminopeptidases catalyze the removal of a penultimate prolyl residue from the N termini of peptides. Mammalian X-prolyl aminopeptidases are shown to be responsible for the degradation of bradykinin, a blood pressure regulator peptide, and have been linked to myocardial infarction ...

    X-prolyl aminopeptidases catalyze the removal of a penultimate prolyl residue from the N termini of peptides. Mammalian X-prolyl aminopeptidases are shown to be responsible for the degradation of bradykinin, a blood pressure regulator peptide, and have been linked to myocardial infarction. The x-ray crystal structure of human cytosolic X-prolyl aminopeptidase (XPN-PEP1) was solved at a resolution of 1.6 angstroms. The structure reveals a dimer with a unique three-domain organization in each subunit, rather than the two domains common to all other known structures of X-prolyl aminopeptidase and prolidases. The C-terminal catalytic domain of XPNPEP1 coordinates two metal ions and shares a similar fold with other prolyl aminopeptidases. Metal content analysis and activity assays confirm that the enzyme is double Mn(II) dependent for its activity, which contrasts with the previous notion that each XPNPEP1 subunit contains only one Mn(II) ion. Activity assays on an E41A mutant demonstrate that the acidic residue, which was considered as a stabilizing factor in the protonation of catalytic residue His498, plays only a marginal role in catalysis. Further mutagenesis reveals the significance of the N-terminal domain and dimerization for the activity of XPNPEP1, and we provide putative structural explanations for their functional roles. Structural comparisons further suggest mechanisms for substrate selectivity in different X-prolyl peptidases.


    Organizational Affiliation

    College of Life Sciences & Tianjin State Laboratory of Protein Sciences, Nankai University, Tianjin 300071, China.



Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
Xaa-Pro aminopeptidase 1623Homo sapiensMutation(s): 0
Gene Names: XPNPEP1XPNPEPLXPNPEPL1
EC: 3.4.11.9
UniProt & NIH Common Fund Data Resources
Find proteins for Q9NQW7 (Homo sapiens)
Explore Q9NQW7
Go to UniProtKB:  Q9NQW7
PHAROS:  Q9NQW7
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ9NQW7
Protein Feature View
Expand
  • Reference Sequence
Small Molecules
Ligands 4 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
P6G
Query on P6G

Download Ideal Coordinates CCD File
F [auth A]HEXAETHYLENE GLYCOL
C12 H26 O7
IIRDTKBZINWQAW-UHFFFAOYSA-N
 Ligand Interaction
MN
Query on MN

Download Ideal Coordinates CCD File
B [auth A],
C [auth A]
MANGANESE (II) ION
Mn
WAEMQWOKJMHJLA-UHFFFAOYSA-N
 Ligand Interaction
CA
Query on CA

Download Ideal Coordinates CCD File
D [auth A]CALCIUM ION
Ca
BHPQYMZQTOCNFJ-UHFFFAOYSA-N
 Ligand Interaction
NA
Query on NA

Download Ideal Coordinates CCD File
E [auth A]SODIUM ION
Na
FKNQFGJONOIPTF-UHFFFAOYSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.60 Å
  • R-Value Free: 0.196
  • R-Value Work: 0.154
  • R-Value Observed: 0.156
  • Space Group: C 2 2 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 71.444α = 90
b = 131.429β = 90
c = 169.076γ = 90
Software Package:
Software NamePurpose
REFMACrefinement

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2008-05-27
    Type: Initial release
  • Version 1.1: 2011-07-13
    Changes: Version format compliance
  • Version 1.2: 2014-01-29
    Changes: Database references
