3BT6

Crystal Structure of Influenza B Virus Hemagglutinin


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.8 Å
  • R-Value Free: 0.309
  • R-Value Work: 0.280

wwPDB Validation 3D Report Full Report


This is version 1.1 of the entry. See complete history

Literature

Crystal structure of unliganded influenza B virus hemagglutinin.

Wang, Q.Cheng, F.Lu, M.Tian, X.Ma, J.

(2008) J.Virol. 82: 3011-3020

  • DOI: 10.1128/JVI.02477-07

  • PubMed Abstract:
  • Here we report the crystal structure of hemagglutinin (HA) from influenza B/Hong Kong/8/73 (B/HK) virus determined to 2.8 A. At a sequence identity of approximately 25% to influenza A virus HAs, B/HK HA shares a similar overall structure and domain o ...

    Here we report the crystal structure of hemagglutinin (HA) from influenza B/Hong Kong/8/73 (B/HK) virus determined to 2.8 A. At a sequence identity of approximately 25% to influenza A virus HAs, B/HK HA shares a similar overall structure and domain organization. More than two dozen amino acid substitutions on influenza B virus HAs have been identified to cause antigenicity alteration in site-specific mutants, monoclonal antibody escape mutants, or field isolates. Mapping these substitutions on the structure of B/HK HA reveals four major epitopes, the 120 loop, the 150 loop, the 160 loop, and the 190 helix, that are located close in space to form a large, continuous antigenic site. Moreover, a systematic comparison of known HA structures across the entire influenza virus family reveals evolutionarily conserved ionizable residues at all regions along the chain and subunit interfaces. These ionizable residues are likely the structural basis for the pH dependence and sensitivity to ionic strength of influenza HA and hemagglutinin-esterase fusion proteins.


    Organizational Affiliation

    Department of Biochemistry and Molecular Biology, Baylor College of Medicine, One Baylor Plaza, BCM-125, Houston, TX 77030, USA. qinghuaw@bcm.tmc.edu




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
Influenza B hemagglutinin (HA)
A
342Influenza B virus (strain B/Hong Kong/8/1973)Mutation(s): 0
Gene Names: HA
Find proteins for P03462 (Influenza B virus (strain B/Hong Kong/8/1973))
Go to UniProtKB:  P03462
Entity ID: 2
MoleculeChainsSequence LengthOrganismDetails
Influenza B hemagglutinin (HA)
B
169Influenza B virus (strain B/Hong Kong/8/1973)Mutation(s): 0
Gene Names: HA
Find proteins for P03462 (Influenza B virus (strain B/Hong Kong/8/1973))
Go to UniProtKB:  P03462
Small Molecules
Ligands 3 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
SO4
Query on SO4

Download SDF File
Download CCD File
B
SULFATE ION
O4 S
QAOWNCQODCNURD-UHFFFAOYSA-L
 Ligand Interaction
NDG
Query on NDG

Download SDF File
Download CCD File
A
2-(ACETYLAMINO)-2-DEOXY-A-D-GLUCOPYRANOSE
C8 H15 N O6
OVRNDRQMDRJTHS-PVFLNQBWSA-N
 Ligand Interaction
NAG
Query on NAG

Download SDF File
Download CCD File
A, B
N-ACETYL-D-GLUCOSAMINE
C8 H15 N O6
OVRNDRQMDRJTHS-FMDGEEDCSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.8 Å
  • R-Value Free: 0.309
  • R-Value Work: 0.280
  • Space Group: P 3 2 1
Unit Cell:
Length (Å)Angle (°)
a = 98.296α = 90.00
b = 98.296β = 90.00
c = 135.838γ = 120.00
Software Package:
Software NamePurpose
REFMACrefinement
HKL-2000data reduction
HKL-2000data collection
PDB_EXTRACTdata extraction
HKL-2000data scaling
SOLVEphasing

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2008-05-27
    Type: Initial release
  • Version 1.1: 2011-07-13
    Type: Non-polymer description, Version format compliance
