3BDE | pdb_00003bde

Crystal structure of a dabb family protein with a ferredoxin-like fold (mll5499) from mesorhizobium loti maff303099 at 1.79 A resolution

• PDB DOI: https://doi.org/10.2210/pdb3BDE/pdb

• Classification: UNKNOWN FUNCTION
• Organism(s): Mesorhizobium japonicum MAFF 303099
• Expression System: Escherichia coli
• Mutation(s): No


• Deposited: 2007-11-14 Released: 2007-11-27
• Deposition Author(s): Joint Center for Structural Genomics (JCSG)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.79 Å
• R-Value Free:
  0.224 (Depositor), 0.240 (DCC)
• R-Value Work:
  0.177 (Depositor), 0.190 (DCC)
• R-Value Observed:
  0.179 (Depositor)

Literature

Crystal structure of domain of unknown function with a ferredoxin-like fold (NP_106155.1) from Mesorhizobium loti at 1.79 A resolution

Joint Center for Structural Genomics (JCSG)

To be published.

Biological Assembly 1

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 1 assigned by authors and generated by PISA (software)

Biological Assembly Evidence: gel filtration, light scattering

Biological Assembly 2

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 2 assigned by authors and generated by PISA (software)

Biological Assembly Evidence: gel filtration, light scattering

Macromolecule Content

• Total Structure Weight: 29.68 kDa
• Atom Count: 1,989
• Modeled Residue Count: 199
• Deposited Residue Count: 240
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Mll5499 protein	A, B	120	Mesorhizobium japonicum MAFF 303099	Mutation(s): 0  Gene Names: NP_106155.1, mll5499
UniProt
Find proteins for Q98BN1 (Mesorhizobium japonicum (strain LMG 29417 / CECT 9101 / MAFF 303099)) Explore Q98BN1  Go to UniProtKB:  Q98BN1

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
EDO	D [auth A], E [auth A], F [auth A], G [auth A], H [auth A], I [auth A], J [auth A], K [auth A], L [auth B], M [auth B], N [auth B], O [auth B], P [auth B], Q [auth B], R [auth B]	1,2-ETHANEDIOL C2 H6 O2 LYCAIKOWRPUZTN-UHFFFAOYSA-N
ACT	C [auth A]	ACETATE ION C2 H3 O2 QTBSBXVTEAMEQO-UHFFFAOYSA-M

Modified Residues  1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE	A, B	L-PEPTIDE LINKING	C5 H11 N O2 Se		MET

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.79 Å
• R-Value Free:  0.224 (Depositor), 0.240 (DCC)
• R-Value Work:  0.177 (Depositor), 0.190 (DCC)
• R-Value Observed: 0.179 (Depositor)

Diffraction Data: https://doi.org/10.18430/M33BDE

Space Group: C 1 2 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 118.669	α = 90
b = 28.415	β = 117.78
c = 76.985	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
PHENIX	refinement
SHELX	phasing
MolProbity	model building
SCALA	data scaling
PDB_EXTRACT	data extraction
ADSC	data collection
MOSFLM	data reduction
SHELXD	phasing
SHARP	phasing

Structure Validation

Entry History

Deposition Data

• Released Date: 2007-11-27
Deposition Author(s): Joint Center for Structural Genomics (JCSG)

Revision History

• Version 1.0: 2007-11-27
  Type: Initial release

• Version 1.1: 2011-07-13
  Changes: Advisory, Source and taxonomy, Version format compliance
• Version 1.2: 2017-10-25
  Changes: Author supporting evidence, Refinement description
• Version 1.3: 2019-07-24
  Changes: Data collection, Derived calculations, Refinement description
• Version 1.4: 2023-01-25
  Changes: Database references, Derived calculations
• Version 1.5: 2024-11-06
  Changes: Data collection, Structure summary
