3B1F

Crystal structure of prephenate dehydrogenase from Streptococcus mutans


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.10 Å
  • R-Value Free: 0.234
  • R-Value Work: 0.193
  • R-Value Observed: 0.195

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.0 of the entry. See complete history


Literature

Crystal structure of prephenate dehydrogenase from Streptococcus mutans.

Ku, H.K.Do, N.H.Song, J.S.Choi, S.Yeon, S.H.Shin, M.H.Kim, K.J.Park, S.R.Park, I.Y.Kim, S.K.Lee, S.J.

(2011) Int J Biol Macromol 49: 761-766

  • DOI: 10.1016/j.ijbiomac.2011.07.009
  • Primary Citation of Related Structures:
    3B1F

  • PubMed Abstract:
  • Prephenate dehydrogenase (PDH) is a bacterial enzyme that catalyzes conversion of prephenate to 4-hydroxyphenylpyruvate through the oxidative decarboxylation pathway for tyrosine biosynthesis. This enzymatic pathway exists in prokaryotes but is absent in mammals, indicating that it is a potential target for the development of new antibiotics ...

    Prephenate dehydrogenase (PDH) is a bacterial enzyme that catalyzes conversion of prephenate to 4-hydroxyphenylpyruvate through the oxidative decarboxylation pathway for tyrosine biosynthesis. This enzymatic pathway exists in prokaryotes but is absent in mammals, indicating that it is a potential target for the development of new antibiotics. The crystal structure of PDH from Streptococcus mutans in a complex with NAD(+) shows that the enzyme exists as a homo-dimer, each monomer consisting of two domains, a modified nucleotide binding N-terminal domain and a helical prephenate C-terminal binding domain. The latter is the dimerization domain. A structural comparison of PDHs from mesophilic S. mutans and thermophilic Aquifex aeolicus showed differences in the long loop between β6 and β7, which may be a reason for the high K(m) values of PDH from Streptococcus mutans.


    Organizational Affiliation

    Division of Metrology for Quality of Life, Department of Bio-Analytical Science, University of Science & Technology, Daejeon, Republic of Korea.



Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
Putative prephenate dehydrogenaseA290Streptococcus mutansMutation(s): 0
Gene Names: SMU_781
EC: 1.3.1.12
UniProt
Find proteins for Q8DUW0 (Streptococcus mutans serotype c (strain ATCC 700610 / UA159))
Explore Q8DUW0
Go to UniProtKB:  Q8DUW0
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ8DUW0
Protein Feature View
Expand
  • Reference Sequence
Small Molecules
Ligands 1 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
NAD
Query on NAD

Download Ideal Coordinates CCD File
B [auth A]NICOTINAMIDE-ADENINE-DINUCLEOTIDE
C21 H27 N7 O14 P2
BAWFJGJZGIEFAR-NNYOXOHSSA-N
 Ligand Interaction
Modified Residues  1 Unique
IDChainsTypeFormula2D DiagramParent
MSE
Query on MSE
A L-PEPTIDE LINKINGC5 H11 N O2 SeMET
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.10 Å
  • R-Value Free: 0.234
  • R-Value Work: 0.193
  • R-Value Observed: 0.195
  • Space Group: C 2 2 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 79.34α = 90
b = 145.624β = 90
c = 77.552γ = 90
Software Package:
Software NamePurpose
HKL-2000data collection
SOLVEphasing
REFMACrefinement
HKL-2000data reduction
HKL-2000data scaling

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2011-10-26
    Type: Initial release
