Crystal structure of a class V chitinase from Arabidopsis thaliana

Experimental Data Snapshot

  • Resolution: 2.01 Å
  • R-Value Free: 0.227
  • R-Value Work: 0.196
  • R-Value Observed: 0.198

wwPDB Validation   3D Report Full Report

This is version 1.1 of the entry. See complete history


A class V chitinase from Arabidopsis thaliana: gene responses, enzymatic properties, and crystallographic analysis

Ohnuma, T.Numata, T.Osawa, T.Mizuhara, M.Lampela, O.Juffer, A.H.Skriver, K.Fukamizo, T.

(2011) Planta 234: 123-137

  • DOI: https://doi.org/10.1007/s00425-011-1390-3
  • Primary Citation of Related Structures:

  • PubMed Abstract:

    Expression of a class V chitinase gene (At4g19810, AtChiC) in Arabidopsis thaliana was examined by quantitative real-time PCR and by analyzing microarray data available at Genevestigator. The gene expression was induced by the plant stress-related hormones abscisic acid (ABA) and jasmonic acid (JA) and by the stress resulting from the elicitor flagellin, NaCl, and osmosis. The recombinant AtChiC protein was produced in E. coli, purified, and characterized with respect to the structure and function. The recombinant AtChiC hydrolyzed N-acetylglucosamine oligomers producing dimers from the non-reducing end of the substrates. The crystal structure of AtChiC was determined by the molecular replacement method at 2.0 Å resolution. AtChiC was found to adopt an (β/α)(8) fold with a small insertion domain composed of an α-helix and a five-stranded β-sheet. From docking simulation of AtChiC with pentameric substrate, the amino acid residues responsible for substrate binding were found to be well conserved when compared with those of the class V chitinase from Nicotiana tabacum (NtChiV). All of the structural and functional properties of AtChiC are quite similar to those obtained for NtChiV, and seem to be common to class V chitinases from higher plants.

  • Organizational Affiliation

    Department of Advanced Bioscience, Kinki University, 3327-204 Nakamachi, Nara 631-8505, Japan.

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
A, B, C, D
356Arabidopsis thalianaMutation(s): 0
Gene Names: At4g19810ChiCT16H5.170
EC: (PDB Primary Data), (UniProt)
Find proteins for O81862 (Arabidopsis thaliana)
Explore O81862
Go to UniProtKB:  O81862
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupO81862
Sequence Annotations
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Resolution: 2.01 Å
  • R-Value Free: 0.227
  • R-Value Work: 0.196
  • R-Value Observed: 0.198
  • Space Group: P 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 74.574α = 73.63
b = 75.079β = 73.34
c = 97.347γ = 68.47
Software Package:
Software NamePurpose
HKL-2000data collection
HKL-2000data reduction
HKL-2000data scaling

Structure Validation

View Full Validation Report

Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2011-07-20
    Type: Initial release
  • Version 1.1: 2023-11-01
    Changes: Data collection, Database references, Derived calculations, Refinement description
