Experimental Data Snapshot

  • Resolution: 2.50 Å
  • R-Value Free: 0.245
  • R-Value Work: 0.212
  • R-Value Observed: 0.212

wwPDB Validation   3D Report Full Report

This is version 1.3 of the entry. See complete history


Crystal structures of the transcriptional repressor RolR reveals a novel recognition mechanism between inducer and regulator.

Li, D.F.Zhang, N.Hou, Y.J.Huang, Y.Hu, Y.Zhang, Y.Liu, S.J.Wang, D.C.

(2011) PLoS One 6: e19529-e19529

  • DOI: https://doi.org/10.1371/journal.pone.0019529
  • Primary Citation of Related Structures:
    3AQS, 3AQT

  • PubMed Abstract:

    Many members of the TetR family control the transcription of genes involved in multidrug resistance and pathogenicity. RolR (ResorcinolRegulator), the recently reported TetR-type regulator for aromatic catabolism from Corynebacterium glutamicum, distinguishes itself by low sequence similarities and different regulation from the previously known members of the TetR family. Here we report the crystal structures of RolR in its effector-bound (with resorcinol) and aop- forms at 2.5 Å and 3.6 Å, respectively. The structure of resorcinol-RolR complex reveal that the hydrogen-bonded network mediated by the four-residue motif (Asp94- Arg145- Arg148- Asp149) with two water molecules and the hydrophobic interaction via five residues (Phe107, Leu111, Leu114, Leu142, and Phe172) are the key factors for the recognition and binding between the resorcinol and RolR molecules. The center-to-center separation of the recognition helices h3-h3' is decreased upon effector-binding from 34.9 Å to 30.4 Å. This structural change results in that RolR was unsuitable for DNA binding. Those observations are distinct from that in other TetR members. Structure-based mutagenesis on RolR was carried out and the results confirmed the critical roles of the above mentioned residues for effector-binding specificity and affinity. Similar sequence searches and sequence alignments identified 29 RolR homologues from GenBank, and all the above mentioned residues are highly conserved in the homologues. Based on these structural and other functional investigations, it is proposed that RolR may represent a new subfamily of TetR proteins that are invovled in aromatic degradation and sharing common recognition mode as for RolR.

  • Organizational Affiliation

    National Laboratory of Biomacromolecules, Institute of Biophysics, Chinese Academy of Sciences, Beijing, People's Republic of China.

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Bacterial regulatory proteins, tetR family
A, B
245Corynebacterium glutamicum ATCC 13032Mutation(s): 0
Gene Names: cg1308Cgl1157ncgl1110
Find proteins for Q8NR95 (Corynebacterium glutamicum (strain ATCC 13032 / DSM 20300 / BCRC 11384 / JCM 1318 / LMG 3730 / NCIMB 10025))
Explore Q8NR95
Go to UniProtKB:  Q8NR95
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ8NR95
Sequence Annotations
  • Reference Sequence
Small Molecules
Modified Residues  1 Unique
IDChains TypeFormula2D DiagramParent
Query on MSE
A, B
Binding Affinity Annotations
IDSourceBinding Affinity
RCO PDBBind:  3AQT Kd: 190 (nM) from 1 assay(s)
Binding MOAD:  3AQT Kd: 190 (nM) from 1 assay(s)
Experimental Data & Validation

Experimental Data

  • Resolution: 2.50 Å
  • R-Value Free: 0.245
  • R-Value Work: 0.212
  • R-Value Observed: 0.212
  • Space Group: I 2 3
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 167.12α = 90
b = 167.12β = 90
c = 167.12γ = 90
Software Package:
Software NamePurpose
ADSCdata collection
HKL-2000data reduction
DENZOdata reduction
SCALEPACKdata scaling

Structure Validation

View Full Validation Report

Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2011-07-06
    Type: Initial release
  • Version 1.1: 2011-07-13
    Changes: Version format compliance
  • Version 1.2: 2013-11-06
    Changes: Experimental preparation
  • Version 1.3: 2017-10-11
    Changes: Advisory, Refinement description
