2ZBN

Crystal structure of PH1033 from Pyrococcus horikoshii OT3


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.00 Å
  • R-Value Free: 0.251
  • R-Value Work: 0.244
  • R-Value Observed: 0.244

wwPDB Validation   3D Report Full Report


This is version 1.1 of the entry. See complete history


Literature

Nucleant-mediated protein crystallization with the application of microporous synthetic zeolites.

Sugahara, M.Asada, Y.Morikawa, Y.Kageyama, Y.Kunishima, N.

(2008) Acta Crystallogr D Biol Crystallogr 64: 686-695

  • DOI: 10.1107/S0907444908009980
  • Primary Citation of Related Structures:
    1WMM, 2DPN, 2HD9, 2ZBN

  • PubMed Abstract:
  • Protein crystallization is still a major bottleneck in structural biology. As the current methodology of protein crystallization is a type of screening, it is usually difficult to crystallize important target proteins. It was thought that hetero-epitaxic growth from the surface of a mineral crystal acting as a nucleant would be an effective enhancer of protein crystallization ...

    Protein crystallization is still a major bottleneck in structural biology. As the current methodology of protein crystallization is a type of screening, it is usually difficult to crystallize important target proteins. It was thought that hetero-epitaxic growth from the surface of a mineral crystal acting as a nucleant would be an effective enhancer of protein crystallization. However, in spite of almost two decades of effort, a generally applicable hetero-epitaxic nucleant for protein crystallization has yet to be found. Here we introduce the first candidate for a universal hetero-epitaxic nucleant, microporous zeolite: a synthetic aluminosilicate crystalline polymer with regular micropores. It promotes a form-selective crystal nucleation of proteins and acts as a crystallization catalyst. The most successful zeolite nucleant was molecular sieve type 5A with a pore size of 5 A and with bound Ca2+ ions. The zeolite-mediated crystallization improved the crystal quality in five out of six proteins tested. It provided new crystal forms with better resolution in two cases, larger crystals in one case, and zeolite-dependent crystal formations in two cases. The hetero-epitaxic growth of the zeolite-mediated crystals was confirmed by a crystal-packing analysis which revealed a layer-like structure in the crystal lattice.


    Organizational Affiliation

    RIKEN SPring-8 Center, Harima Institute, 1-1-1 Kouto, Sayo-cho, Sayo-gun, Hyogo 679-5148, Japan.



Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
UPF0310 protein PH1033A145Pyrococcus horikoshii OT3Mutation(s): 0
Gene Names: PH1033
UniProt
Find proteins for O58764 (Pyrococcus horikoshii (strain ATCC 700860 / DSM 12428 / JCM 9974 / NBRC 100139 / OT-3))
Explore O58764
Go to UniProtKB:  O58764
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupO58764
Protein Feature View
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.00 Å
  • R-Value Free: 0.251
  • R-Value Work: 0.244
  • R-Value Observed: 0.244
  • Space Group: P 31 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 95.035α = 90
b = 95.035β = 90
c = 44.536γ = 120
Software Package:
Software NamePurpose
CNSrefinement
HKL-2000data collection
HKL-2000data reduction
HKL-2000data scaling
MOLREPphasing

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2008-04-29
    Type: Initial release
  • Version 1.1: 2011-07-13
    Changes: Source and taxonomy, Version format compliance
