2ZA4 | pdb_00002za4

Crystal Structural Analysis of Barnase-barstar Complex


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.58 Å
  • R-Value Free:
    0.200 (Depositor), 0.199 (DCC)
  • R-Value Work:
    0.199 (Depositor), 0.199 (DCC)
  • R-Value Observed:
    0.199 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 2ZA4

This is version 1.3 of the entry. See complete history

Literature

Crystal structural analysis of protein-protein interactions drastically destabilized by a single mutation

Urakubo, Y.Ikura, T.Ito, N.

(2008) Protein Sci 17: 1055-1065

  • DOI: https://doi.org/10.1110/ps.073322508
  • Primary Citation Related Structures:
    2ZA4

  • PubMed Abstract:

    The complex of barnase (bn) and barstar (bs), which has been widely studied as a model for quantitative analysis of protein-protein interactions, is significantly destabilized by a single mutation, namely, bs Asp39 --> Ala, which corresponds to a change of 7.7 kcal x mol(-1) in the free energy of binding. However, there has been no structural information available to explain such a drastic destabilization. In the present study, we determined the structure of the mutant complex at 1.58 A resolution by X-ray crystallography. The complex was similar to the wild-type complex in terms of overall and interface structures; however, the hydrogen bond network mediated by water molecules at the interface was significantly different. Several water molecules filled the cavity created by the mutation and consequently caused rearrangement of the hydrated water molecules at the interface. The water molecules were redistributed into a channel-like structure that penetrated into the complex. Furthermore, molecular dynamics simulations showed that the mutation increased the mobility of water molecules at the interface. Since such a drastic change in hydration was not observed in other mutant complexes of bn and bs, the significant destabilization of the interaction may be due to this channel-like structure of hydrated water molecules.


  • Organizational Affiliation
    • Laboratory of Structural Biology, School of Biomedical Science, Tokyo Medical and Dental University, Tokyo 113-8510, Japan.

Macromolecule Content

  • Total Structure Weight: 45.24 kDa
  • Atom Count: 3,560
  • Modeled Residue Count: 390
  • Deposited Residue Count: 400
  • Unique protein chains: 2

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Ribonuclease
A, C
110Bacillus amyloliquefaciensMutation(s): 1
EC: 3.1.27
UniProt
Find proteins for P00648 (Bacillus amyloliquefaciens)
Explore P00648
Go to UniProtKB:  P00648
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP00648
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 2
MoleculeChains  Sequence LengthOrganismDetailsImage
Barstar
B, D
90Bacillus amyloliquefaciensMutation(s): 3
UniProt
Find proteins for P11540 (Bacillus amyloliquefaciens)
Explore P11540
Go to UniProtKB:  P11540
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP11540
Sequence Annotations
Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.58 Å
  • R-Value Free:  0.200 (Depositor), 0.199 (DCC)
  • R-Value Work:  0.199 (Depositor), 0.199 (DCC)
  • R-Value Observed: 0.199 (Depositor)
Space Group: C 1 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 97.388α = 90
b = 110.255β = 114.97
c = 47.272γ = 90
Software Package:
Software NamePurpose
CNSrefinement
ADSCdata collection
HKL-2000data reduction
HKL-2000data scaling
CNSphasing

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2008-05-20
    Type: Initial release
  • Version 1.1: 2011-07-13
    Changes: Version format compliance
  • Version 1.2: 2021-11-10
    Changes: Database references, Derived calculations
  • Version 1.3: 2023-11-01
    Changes: Data collection, Refinement description
