2Z38 | pdb_00002z38

Crystal structure of chloride bound Brassica juncea chitinase catalytic module (Bjchi3)


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.80 Å
  • R-Value Free:
    0.198 (Depositor), 0.235 (DCC)
  • R-Value Work:
    0.155 (Depositor)
  • R-Value Observed:
    0.157 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 2Z38

This is version 1.5 of the entry. See complete history

Literature

Crystal structures of a family 19 chitinase from Brassica juncea show flexibility of binding cleft loops

Ubhayasekera, W.Tang, C.M.Ho, S.W.T.Berglund, G.Bergfors, T.Chye, M.-L.Mowbray, S.L.

(2007) FEBS J 274: 3695-3703

  • DOI: https://doi.org/10.1111/j.1742-4658.2007.05906.x
  • Primary Citation Related Structures:
    2Z37, 2Z38, 2Z39

  • PubMed Abstract:

    Brassica juncea chitinase is an endo-acting, pathogenesis-related protein that is classified into glycoside hydrolase family 19, with highest homology (50-60%) in its catalytic domain to class I plant chitinases. Here we report X-ray structures of the chitinase catalytic domain from wild-type (apo, as well as with chloride ions bound) and a Glu234Ala mutant enzyme, solved by molecular replacement and refined at 1.53, 1.8 and 1.7 A resolution, respectively. Confirming our earlier mutagenesis studies, the active-site residues are identified as Glu212 and Glu234. Glu212 is believed to be the catalytic acid in the reaction, whereas Glu234 is thought to have a dual role, both activating a water molecule in its attack on the anomeric carbon, and stabilizing the charged intermediate. The molecules in the various structures differ significantly in the conformation of a number of loops that border the active-site cleft. The differences suggest an opening and closing of the enzyme during the catalytic cycle. Chitin is expected to dock first near Glu212, which will protonate it. Conformational changes then bring Glu234 closer, allowing it to assist in the following steps. These observations provide important insights into catalysis in family 19 chitinases.


  • Organizational Affiliation
    •  Department of Molecular Biology, Swedish University of Agricultural Sciences, Uppsala, Sweden Department of Botany, The University of Hong Kong, Pokfulam, Hong Kong Department of Cell and Molecular Biology, Uppsala University, Sweden.

Macromolecule Content

  • Total Structure Weight: 27.81 kDa
  • Atom Count: 2,197
  • Modeled Residue Count: 247
  • Deposited Residue Count: 247
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Chitinase247Brassica junceaMutation(s): 0
Gene Names: Bjchi1
EC: 3.2.1.14
UniProt
Find proteins for Q9SQF7 (Brassica juncea)
Explore Q9SQF7
Go to UniProtKB:  Q9SQF7
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ9SQF7
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
CL

Query on CL



Download:Ideal Coordinates CCD File
B [auth A]
C [auth A]
D [auth A]
E [auth A]
F [auth A]
B [auth A],
C [auth A],
D [auth A],
E [auth A],
F [auth A],
G [auth A],
H [auth A],
I [auth A],
J [auth A],
K [auth A],
L [auth A],
M [auth A]
CHLORIDE ION
Cl
VEXZGXHMUGYJMC-UHFFFAOYSA-M

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.80 Å
  • R-Value Free:  0.198 (Depositor), 0.235 (DCC)
  • R-Value Work:  0.155 (Depositor)
  • R-Value Observed: 0.157 (Depositor)
Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 48.475α = 90
b = 49.195β = 90
c = 100.907γ = 90
Software Package:
Software NamePurpose
DENZOdata reduction
SCALEPACKdata scaling
PHASERphasing
REFMACrefinement
PDB_EXTRACTdata extraction
ADSCdata collection

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2007-06-19
    Type: Initial release
  • Version 1.1: 2008-04-30
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Version format compliance
  • Version 1.3: 2017-10-11
    Changes: Refinement description
  • Version 1.4: 2023-11-01
    Changes: Data collection, Database references, Derived calculations, Refinement description
  • Version 1.5: 2024-11-13
    Changes: Structure summary
