2Y96

Structure of human dual-specificity phosphatase 27

• PDB DOI: https://doi.org/10.2210/pdb2Y96/pdb

• Classification: HYDROLASE
• Organism(s): Homo sapiens
• Expression System: Escherichia coli BL21(DE3)
• Mutation(s): No


• Deposited: 2011-02-11 Released: 2011-04-27
• Deposition Author(s): Lountos, G.T., Tropea, J.E., Waugh, D.S.

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.38 Å
• R-Value Free: 0.225
• R-Value Work: 0.201
• R-Value Observed: 0.203

Literature

Structure of Human Dual-Specificity Phosphatase at 2.38A Resolution

Lountos, G.T., Tropea, J.E., Waugh, D.S.

(2011) Acta Crystallogr D Biol Crystallogr 67: 471

• PubMed: 21543850
• DOI: https://doi.org/10.1107/S090744491100970X
• Primary Citation of Related Structures:
  2Y96


• PubMed Abstract:


  There are over 100 genes in the human genome that encode protein tyrosine phosphatases (PTPs) and approximately 60 of these are classified as dual-specificity phosphatases (DUSPs). Although many dual-specificity phosphatases are still not well characterized, novel functions have been discovered for some of them that have led to new insights into a variety of biological processes and the molecular basis for certain diseases. Indeed, as the functions of DUSPs continue to be elucidated, a growing number of them are emerging as potential therapeutic targets for diseases such as cancer, diabetes and inflammatory disorders. Here, the overexpression, purification and structure determination of DUSP27 at 2.38 Å resolution are presented.

---

Organizational Affiliation:

Macromolecular Crystallography Laboratory, Center for Cancer Research, National Cancer Institute at Frederick, Frederick, MD 21702, USA.

Biological Assembly 1

Global Symmetry: Dihedral - D2  (Explore in 3D)
Global Stoichiometry: Homo 4-mer - A4

Biological assembly 1 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 51.15 kDa
• Atom Count: 2,946
• Modelled Residue Count: 340
• Deposited Residue Count: 438
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
DUAL SPECIFICITY PHOSPHATASE DUPD1	A, B	219	Homo sapiens	Mutation(s): 0  EC: 3.1.3.16 (PDB Primary Data), 3.1.3.48 (PDB Primary Data)
UniProt & NIH Common Fund Data Resources
Find proteins for Q68J44 (Homo sapiens) Explore Q68J44  Go to UniProtKB:  Q68J44
PHAROS:  Q68J44 GTEx:  ENSG00000188716

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
SO4	C [auth A], D [auth A], E [auth A], F [auth A], G [auth A], H [auth B], I [auth B]	SULFATE ION O4 S QAOWNCQODCNURD-UHFFFAOYSA-L

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.38 Å
• R-Value Free: 0.225
• R-Value Work: 0.201
• R-Value Observed: 0.203
• Space Group: P 6₄ 2 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 126.012	α = 90
b = 126.012	β = 90
c = 125.758	γ = 120

Software Package:

Software Name	Purpose
REFMAC	refinement
HKL-3000	data reduction
SCALEPACK	data scaling
PHASER	phasing

Structure Validation

Entry History

Deposition Data

• Released Date: 2011-04-27
Deposition Author(s): Lountos, G.T., Tropea, J.E., Waugh, D.S.

Revision History

• Version 1.0: 2011-04-27
  Type: Initial release

• Version 1.1: 2011-05-26
  Changes: Version format compliance
• Version 1.2: 2011-07-13
  Changes: Version format compliance
• Version 1.3: 2023-12-20
  Changes: Data collection, Database references, Derived calculations, Other, Refinement description
