2WVP | pdb_00002wvp

Synthetically modified OmpG

PDB DOI: https://doi.org/10.2210/pdb2WVP/pdb

Classification: MEMBRANE PROTEIN
Organism(s): Escherichia coli K-12
Expression System: Escherichia coli BL21(DE3)
Mutation(s): Yes
Membrane Protein: Yes PDBTM MemProtMD

Deposited: 2009-10-19 Released: 2010-07-14
Deposition Author(s): Grosse, W., Reiss, P., Reitz, S., Cebi, M., Luebben, W., Koert, U., Essen, L.-O.

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.40 Å
R-Value Free:
0.287 (Depositor), 0.292 (DCC)
R-Value Work:
0.221 (Depositor), 0.233 (DCC)
R-Value Observed:
0.224 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.4 of the entry. See complete history.

Literature

Structural and Functional Characterization of a Synthetically Modified Ompg.

Grosse, W., Reiss, P., Reitz, S., Cebi, M., Luebben, W., Koert, U., Essen, L.-O.

(2010) Bioorg Med Chem 18: 7716

PubMed: 20378361 Search on PubMed
DOI: https://doi.org/10.1016/j.bmc.2010.03.044
Primary Citation Related Structures:
2WVP

PubMed Abstract:
Chemical modification of ion channels has recently attracted attention due to their potential use in stochastic sensing and neurobiology. Among the available channel templates stable β-barrel proteins have shown their potential for large scale chemical modifications due to their wide pore lumen. Ion-channel hybrids using the outer membrane protein OmpG were generated by S-alkylation with a synthetic modulator and functionally as well as structurally characterized. The dansyl moiety of the used modulator resulted in partial blockage of current though the OmpG channel with its gating characteristics mainly unaffected. The crystal structure of an OmpG-dansyl hybrid at 2.4Å resolution correlates this finding by showing that the modulator lines the inner walling of the OmpG pore. These results underline the suitability of OmpG as a structural base for the construction of stochastic sensors.

Organizational Affiliation

Philipps-Universität Marburg, Fachbereich Chemie, Hans-Meerwein-Straße, 35032 Marburg, Germany.

Macromolecule Content

Total Structure Weight: 35.94 kDa
Atom Count: 2,421
Modeled Residue Count: 262
Deposited Residue Count: 286
Unique protein chains: 1

Macromolecules

Find similar proteins by:

| 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
OUTER MEMBRANE PROTEIN G	A	286	Escherichia coli K-12	Mutation(s): 1 Membrane Entity: Yes
UniProt
Find proteins for P76045 (Escherichia coli (strain K12)) Explore P76045 Go to UniProtKB: P76045
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	P76045
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 3 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
420 Query on 420 Download:Ideal Coordinates CCD File SDF format, chain B [auth A] MOL2 format, chain B [auth A] mmCIF format, chain B [auth A]	B [auth A]	N-[2-({[5-(DIMETHYLAMINO)NAPHTHALEN-1-YL]SULFONYL}AMINO)ETHYL]-2-IODOACETAMIDE C₁₆ H₂₀ I N₃ O₃ S QDHGMMDEGVINBU-UHFFFAOYSA-N		Interactions Focus chain B [auth A] Interactions & Density Focus chain B [auth A]
C8E Query on C8E Download:Ideal Coordinates CCD File SDF format, chain C [auth A] SDF format, chain H [auth A] SDF format, chain G [auth A] SDF format, chain F [auth A] SDF format, chain E [auth A] SDF format, chain D [auth A] MOL2 format, chain C [auth A] MOL2 format, chain H [auth A] MOL2 format, chain G [auth A] MOL2 format, chain F [auth A] MOL2 format, chain E [auth A] MOL2 format, chain D [auth A] mmCIF format, chain C [auth A] mmCIF format, chain H [auth A] mmCIF format, chain G [auth A] mmCIF format, chain F [auth A] mmCIF format, chain E [auth A] mmCIF format, chain D [auth A]	C [auth A] D [auth A] E [auth A] F [auth A] G [auth A] C [auth A], D [auth A], E [auth A], F [auth A], G [auth A], H [auth A]	(HYDROXYETHYLOXY)TRI(ETHYLOXY)OCTANE C₁₆ H₃₄ O₅ FEOZZFHAVXYAMB-UHFFFAOYSA-N		Interactions Focus chain C [auth A] Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Focus chain H [auth A] Interactions & Density Focus chain C [auth A] Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Focus chain H [auth A]
EDO Query on EDO Download:Ideal Coordinates CCD File SDF format, chain I [auth A] MOL2 format, chain I [auth A] mmCIF format, chain I [auth A]	I [auth A]	1,2-ETHANEDIOL C₂ H₆ O₂ LYCAIKOWRPUZTN-UHFFFAOYSA-N		Interactions Focus chain I [auth A] Interactions & Density Focus chain I [auth A]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.40 Å
R-Value Free: 0.287 (Depositor), 0.292 (DCC)
R-Value Work: 0.221 (Depositor), 0.233 (DCC)
R-Value Observed: 0.224 (Depositor)

Space Group: C 1 2 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 99.56	α = 90
b = 69.81	β = 103.6
c = 59.13	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
XDS	data reduction
SCALA	data scaling
PHASER	phasing

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2010-07-14

Deposition Author(s):

Revision History (Full details and data files)

Version 1.0: 2010-07-14
Type: Initial release
Version 1.1: 2011-05-08
Changes: Version format compliance
Version 1.2: 2011-07-13
Changes: Version format compliance
Version 1.3: 2023-12-20
Changes: Data collection, Database references, Derived calculations, Other, Refinement description
Version 1.4: 2024-11-13
Changes: Structure summary
