2W1J

CRYSTAL STRUCTURE OF SORTASE C-1 (SRTC-1) from Streptococcus pneumoniae


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.24 Å
  • R-Value Free: 0.185
  • R-Value Work: 0.171

wwPDB Validation 3D Report Full Report


This is version 1.2 of the entry. See complete history

Literature

Sortase-Mediated Pilus Fiber Biogenesis in Streptococcus Pneumoniae.

Manzano, C.Contreras-Martel, C.El Mortaji, L.Izore, T.Fenel, D.Vernet, T.Schoehn, G.Di Guilmi, A.M.Dessen, A.

(2008) Structure 16: 1838

  • DOI: 10.1016/j.str.2008.10.007
  • Primary Citation of Related Structures:

  • PubMed Abstract:
  • Streptococcus pneumoniae is a piliated pathogen whose ability to circumvent vaccination and antibiotic treatment strategies is a cause of mortality worldwide. Pili play important roles in pneumococcal infection, but little is known about their biogen ...

    Streptococcus pneumoniae is a piliated pathogen whose ability to circumvent vaccination and antibiotic treatment strategies is a cause of mortality worldwide. Pili play important roles in pneumococcal infection, but little is known about their biogenesis mechanism or the relationship between components of the pilus-forming machinery, which includes the fiber pilin (RrgB), two minor pilins (RrgA, RrgC), and three sortases (SrtC-1, SrtC-2, SrtC-3). Here we show that SrtC-1 is the main pilus-polymerizing transpeptidase, and electron microscopy analyses of RrgB fibers reconstituted in vitro reveal that they structurally mimic the pneumococcal pilus backbone. Crystal structures of both SrtC-1 and SrtC-3 reveal active sites whose access is controlled by flexible lids, unlike in non-pilus sortases, and suggest that substrate specificity is dictated by surface recognition coupled to lid opening. The distinct structural features of pilus-forming sortases suggest a common pilus biogenesis mechanism that could be exploited for the development of broad-spectrum antibacterials.


    Organizational Affiliation

    Laboratoire des Protéines Membranaires, Institut de Biologie Structurale Jean-Pierre Ebel, UMR 5075 (CEA, CNRS, UJF, PSB), 41 rue Jules Horowitz, F-38027 Grenoble, France.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
PUTATIVE SORTASE
A, B
212Streptococcus pneumoniae serotype 4 (strain ATCC BAA-334 / TIGR4)Mutation(s): 0
Find proteins for A0A0H2UNQ9 (Streptococcus pneumoniae serotype 4 (strain ATCC BAA-334 / TIGR4))
Go to UniProtKB:  A0A0H2UNQ9
Small Molecules
Ligands 1 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
GOL
Query on GOL

Download SDF File
Download CCD File
A, B
GLYCEROL
GLYCERIN; PROPANE-1,2,3-TRIOL
C3 H8 O3
PEDCQBHIVMGVHV-UHFFFAOYSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.24 Å
  • R-Value Free: 0.185
  • R-Value Work: 0.171
  • Space Group: P 21 21 21
Unit Cell:
Length (Å)Angle (°)
a = 68.091α = 90.00
b = 70.189β = 90.00
c = 86.542γ = 90.00
Software Package:
Software NamePurpose
SHARPphasing
XSCALEdata scaling
REFMACrefinement
XDSdata reduction

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2008-12-23
    Type: Initial release
  • Version 1.1: 2011-07-13
    Type: Advisory, Version format compliance
  • Version 1.2: 2013-03-06
    Type: Data collection, Derived calculations, Non-polymer description, Refinement description
