Solution Structure of the N-terminal SAP Domain of SUMO E3 Ligases from Oryza sativa

Experimental Data Snapshot

  • Method: SOLUTION NMR
  • Conformers Calculated: 100
  • Conformers Submitted: 20
  • Selection Criteria: structures with the least restraint violations

wwPDB Validation   3D Report Full Report

This is version 1.3 of the entry. See complete history


Solution structures and DNA binding properties of the N-terminal SAP domains of SUMO E3 ligases from Saccharomyces cerevisiae and Oryza sativa.

Suzuki, R.Shindo, H.Tase, A.Kikuchi, Y.Shimizu, M.Yamazaki, T.

(2009) Proteins 75: 336-347

  • DOI: https://doi.org/10.1002/prot.22243
  • Primary Citation of Related Structures:
    2RNN, 2RNO

  • PubMed Abstract:

    SUMO E3 ligase of the Siz/PIAS family that promotes sumoylation of target proteins contains SAP motif in its N-terminal region. The SAP motif with a consensus sequence of 35 residues was first proposed to be as a new DNA binding motif found in diverse nuclear proteins involved in chromosomal organization. We have determined solution structures of the SAP domains of SUMO ligases Siz1 from yeast and rice by NMR spectroscopy, showing that the structure of the SAP domain (residues 2-105) of rice Siz1 is a four-helix bundle with an up-down-extended loop-down-up topology, whereas the SAP domain (residues 1-111) of yeast Siz1 is comprised of five helices where the fifth helix alpha5 causes a significant change in the alignment of the four-helix bundle characteristic to the SAP domains of the Siz/PIAS family. We have also demonstrated that both SAP domains have binding ability to an A/T-rich DNA, but that binding affinity of yeast Siz1 SAP is at least by an order of magnitude higher than that of rice Siz1 SAP. Our NMR titration experiments clearly showed that yeast Siz1 SAP uses alpha2-helix for DNA binding more effectively than rice Siz1 SAP, which would result from the dislocation of this helix due to the existence of the extra helix alpha5. In addition, based on the structures of the SAP domains determined here and registered in Protein Data Bank, general features of structures of the SAP domains are discussed in conjunction with equivocal nature of their DNA binding.

  • Organizational Affiliation

    Protein Research Unit, National Institute of Agrobiological Sciences, Ibaraki 305-8602, Japan.

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Putative DNA-binding protein110Oryza sativa Japonica GroupMutation(s): 0
Gene Names: OSJNBb0079L11.3Os05g0125000
Find proteins for Q6L4L4 (Oryza sativa subsp. japonica)
Explore Q6L4L4
Go to UniProtKB:  Q6L4L4
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ6L4L4
Sequence Annotations
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: SOLUTION NMR
  • Conformers Calculated: 100
  • Conformers Submitted: 20
  • Selection Criteria: structures with the least restraint violations

Structure Validation

View Full Validation Report

Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2008-12-30
    Type: Initial release
  • Version 1.1: 2011-07-13
    Changes: Version format compliance
  • Version 1.2: 2020-02-26
    Changes: Data collection, Database references, Derived calculations, Other
  • Version 1.3: 2024-05-01
    Changes: Data collection, Database references
