2RBD | pdb_00002rbd

CRYSTAL STRUCTURE OF A PUTATIVE SPORE COAT PROTEIN (BH2358) FROM BACILLUS HALODURANS C-125 AT 1.54 A RESOLUTION

• PDB DOI: https://doi.org/10.2210/pdb2RBD/pdb

• Classification: STRUCTURAL PROTEIN
• Organism(s): Halalkalibacterium halodurans C-125
• Expression System: Escherichia coli
• Mutation(s): No


• Deposited: 2007-09-18 Released: 2007-10-02
• Deposition Author(s): Joint Center for Structural Genomics (JCSG)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.54 Å
• R-Value Free:
  0.188 (Depositor), 0.200 (DCC)
• R-Value Work:
  0.159 (Depositor), 0.170 (DCC)
• R-Value Observed:
  0.160 (Depositor)

Literature

Crystal structure of a domain with unknown function and a ferritin-like fold (NP_243224.1) from Bacillus halodurans at 1.54 A resolution

Joint Center for Structural Genomics (JCSG)

To be published.

Biological Assembly 1

Global Symmetry: Dihedral - D2  (Explore in 3D)
Global Stoichiometry: Homo 4-mer - A4

Biological assembly 1 assigned by authors and generated by PISA (software)

Biological Assembly Evidence: gel filtration, light scattering

Macromolecule Content

• Total Structure Weight: 38.97 kDa
• Atom Count: 3,090
• Modeled Residue Count: 315
• Deposited Residue Count: 342
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
BH2358 protein	A, B	171	Halalkalibacterium halodurans C-125	Mutation(s): 0  Gene Names: NP_243224.1, BH2358
UniProt
Find proteins for Q9KAD1 (Halalkalibacterium halodurans (strain ATCC BAA-125 / DSM 18197 / FERM 7344 / JCM 9153 / C-125)) Explore Q9KAD1  Go to UniProtKB:  Q9KAD1

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
PG4	C [auth A], D [auth A], E [auth B]	TETRAETHYLENE GLYCOL C8 H18 O5 UWHCKJMYHZGTIT-UHFFFAOYSA-N

Modified Residues  1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE	A, B	L-PEPTIDE LINKING	C5 H11 N O2 Se		MET

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.54 Å
• R-Value Free:  0.188 (Depositor), 0.200 (DCC)
• R-Value Work:  0.159 (Depositor), 0.170 (DCC)
• R-Value Observed: 0.160 (Depositor)

Diffraction Data: https://doi.org/10.18430/M32RBD

Space Group: I 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 43.082	α = 90
b = 74.345	β = 90
c = 235.812	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
PHENIX	refinement
SHELX	phasing
MolProbity	model building
XSCALE	data scaling
PDB_EXTRACT	data extraction
MAR345	data collection
XDS	data reduction
SHELXD	phasing
SHARP	phasing

Structure Validation

Entry History

Deposition Data

• Released Date: 2007-10-02
Deposition Author(s): Joint Center for Structural Genomics (JCSG)

Revision History

• Version 1.0: 2007-10-02
  Type: Initial release

• Version 1.1: 2011-07-13
  Changes: Version format compliance
• Version 1.2: 2017-10-25
  Changes: Author supporting evidence, Refinement description
• Version 1.3: 2019-07-24
  Changes: Data collection, Derived calculations, Refinement description
• Version 1.4: 2023-01-25
  Changes: Database references, Derived calculations
• Version 1.5: 2024-11-13
  Changes: Data collection, Refinement description, Structure summary
