2R11 | pdb_00002r11

Crystal structure of putative hydrolase (2632844) from Bacillus subtilis at 1.96 A resolution

• PDB DOI: https://doi.org/10.2210/pdb2R11/pdb

• Classification: HYDROLASE
• Organism(s): Bacillus subtilis
• Expression System: Escherichia coli
• Mutation(s): No


• Deposited: 2007-08-21 Released: 2007-09-04
• Deposition Author(s): Joint Center for Structural Genomics (JCSG)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.96 Å
• R-Value Free:
  0.239 (Depositor), 0.240 (DCC)
• R-Value Work:
  0.181 (Depositor), 0.190 (DCC)
• R-Value Observed:
  0.184 (Depositor)

Literature

Crystal structure of putative hydrolase (2632844) from Bacillus subtilis at 1.96 A resolution

Joint Center for Structural Genomics (JCSG)

To be published.

Biological Assembly 1

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 1 assigned by authors and generated by PISA (software)

Biological Assembly 2

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 2 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 141.62 kDa
• Atom Count: 10,230
• Modeled Residue Count: 1,143
• Deposited Residue Count: 1,224
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Carboxylesterase NP	A, B, C, D	306	Bacillus subtilis	Mutation(s): 0  Gene Names: 2632844, nap, BSU05440 EC: 3.1.1.1
UniProt
Find proteins for P96688 (Bacillus subtilis (strain 168)) Explore P96688  Go to UniProtKB:  P96688

Small Molecules

Ligands 4 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
PGE	H [auth C]	TRIETHYLENE GLYCOL C6 H14 O4 ZIBGPFATKBEMQZ-UHFFFAOYSA-N
EDO	G [auth B], I [auth D]	1,2-ETHANEDIOL C2 H6 O2 LYCAIKOWRPUZTN-UHFFFAOYSA-N
CL	E [auth A]	CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M
MG	F [auth B]	MAGNESIUM ION Mg JLVVSXFLKOJNIY-UHFFFAOYSA-N

Modified Residues  1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE	A, B, C, D	L-PEPTIDE LINKING	C5 H11 N O2 Se		MET

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.96 Å
• R-Value Free:  0.239 (Depositor), 0.240 (DCC)
• R-Value Work:  0.181 (Depositor), 0.190 (DCC)
• R-Value Observed: 0.184 (Depositor)

Diffraction Data: https://doi.org/10.18430/M32R11

Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 80.59	α = 90
b = 97.55	β = 110.01
c = 88.27	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
PHENIX	refinement
SHELX	phasing
MolProbity	model building
XSCALE	data scaling
SCALA	data scaling
PDB_EXTRACT	data extraction
MAR345	data collection
XDS	data reduction
autoSHARP	phasing

Structure Validation

Entry History

Deposition Data

• Released Date: 2007-09-04
Deposition Author(s): Joint Center for Structural Genomics (JCSG)

Revision History

• Version 1.0: 2007-09-04
  Type: Initial release

• Version 1.1: 2011-07-13
  Changes: Version format compliance
• Version 1.2: 2017-10-25
  Changes: Refinement description
• Version 1.3: 2019-07-24
  Changes: Data collection, Derived calculations, Refinement description
• Version 1.4: 2023-01-25
  Changes: Database references, Derived calculations
• Version 1.5: 2024-10-16
  Changes: Data collection, Refinement description, Structure summary
