2QXZ

pectate lyase R236F from Xanthomonas campestris


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.12 Å
  • R-Value Free: 0.194
  • R-Value Work: 0.147
  • R-Value Observed: 0.150

wwPDB Validation 3D Report Full Report


This is version 1.1 of the entry. See complete history


Literature

Improvement of the thermostability and activity of a pectate lyase by single amino acid substitutions, using a strategy based on melting-temperature-guided sequence alignment.

Xiao, Z.Bergeron, H.Grosse, S.Beauchemin, M.Garron, M.L.Shaya, D.Sulea, T.Cygler, M.Lau, P.C.

(2008) Appl Environ Microbiol 74: 1183-1189

  • DOI: 10.1128/AEM.02220-07
  • Structures With Same Primary Citation

  • PubMed Abstract:
  • In the vast number of random mutagenesis experiments that have targeted protein thermostability, single amino acid substitutions that increase the apparent melting temperature (Tm) of the enzyme more than 1 to 2 degrees C are rare and often require t ...

    In the vast number of random mutagenesis experiments that have targeted protein thermostability, single amino acid substitutions that increase the apparent melting temperature (Tm) of the enzyme more than 1 to 2 degrees C are rare and often require the creation of a large library of mutated genes. Here we present a case where a single beneficial mutation (R236F) of a hemp fiber-processing pectate lyase of Xanthomonas campestris origin (PL(Xc)) produced a 6 degrees C increase in Tm and a 23-fold increase in the half-life at 45 degrees C without compromising the enzyme's catalytic efficiency. This success was based on a variation of sequence alignment strategy where a mesophilic amino acid sequence is matched with the sequences of its thermophilic counterparts that have established Tm values. Altogether, two-thirds of the nine targeted single amino acid substitutions were found to have effects either on the thermostability or on the catalytic activity of the enzyme, evidence of a high success rate of mutation without the creation of a large gene library and subsequent screening of clones. Combination of R236F with another beneficial mutation (A31G) resulted in at least a twofold increase in specific activity while preserving the improved Tm value. To understand the structural basis for the increased thermal stability or activity, the variant R236F and A31G R236F proteins and wild-type PL(Xc) were purified and crystallized. By structure analysis and computational methods, hydrophobic desolvation was found to be the driving force for the increased stability with R236F.


    Organizational Affiliation

    Biotechnology Research Institute, National Research Council Canada, 6100 Royalmount Avenue, Montreal, Quebec H4P 2R2, Canada.



Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
pectate lyase IIA, B330Xanthomonas campestris pv. campestrisMutation(s): 1
Find proteins for Q8P6Z9 (Xanthomonas campestris pv. campestris (strain ATCC 33913 / DSM 3586 / NCPPB 528 / LMG 568 / P 25))
Explore Q8P6Z9
Go to UniProtKB:  Q8P6Z9
Protein Feature View
 ( Mouse scroll to zoom / Hold left click to move )
  • Reference Sequence
Small Molecules
Ligands 1 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
PO4
Query on PO4

Download CCD File
A, B
PHOSPHATE ION
O4 P
NBIIXXVUZAFLBC-UHFFFAOYSA-K
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.12 Å
  • R-Value Free: 0.194
  • R-Value Work: 0.147
  • R-Value Observed: 0.150
  • Space Group: P 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 47.329α = 71.9
b = 53.169β = 80.23
c = 73.218γ = 69.11
Software Package:
Software NamePurpose
REFMACrefinement
HKL-2000data collection
HKL-2000data reduction
HKL-2000data scaling
CNSphasing

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History

  • Version 1.0: 2008-03-04
    Type: Initial release
  • Version 1.1: 2011-07-13
    Changes: Advisory, Version format compliance
