2QXY | pdb_00002qxy

Crystal structure of a response regulator from Thermotoga maritima

• PDB DOI: https://doi.org/10.2210/pdb2QXY/pdb

• Classification: TRANSCRIPTION
• Organism(s): Thermotoga maritima
• Expression System: Escherichia coli BL21(DE3)
• Mutation(s): No


• Deposited: 2007-08-13 Released: 2007-08-28
• Deposition Author(s): Palani, K., Kumaran, D., Burley, S.K., Swaminathan, S., New York SGX Research Center for Structural Genomics (NYSGXRC)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.95 Å
• R-Value Free:
  0.240 (Depositor), 0.240 (DCC)
• R-Value Work:
  0.219 (Depositor), 0.220 (DCC)
• R-Value Observed:
  0.219 (Depositor)

Literature

Crystal structure of a response regulator from Thermotoga maritima.

Palani, K., Kumaran, D., Burley, S.K., Swaminathan, S.

To be published.

Biological Assembly 1

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 1 assigned by authors.

Biological Assembly 2

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 2 generated by PISA (software)

Biological Assembly 3

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 3 generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 33.26 kDa
• Atom Count: 2,113
• Modeled Residue Count: 236
• Deposited Residue Count: 284
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Response regulator	A, B	142	Thermotoga maritima	Mutation(s): 0  Gene Names: TM_0842
UniProt
Find proteins for Q9WZU6 (Thermotoga maritima (strain ATCC 43589 / DSM 3109 / JCM 10099 / NBRC 100826 / MSB8)) Explore Q9WZU6  Go to UniProtKB:  Q9WZU6

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
SO4	C [auth A]	SULFATE ION O4 S QAOWNCQODCNURD-UHFFFAOYSA-L

Modified Residues  1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE	A, B	L-PEPTIDE LINKING	C5 H11 N O2 Se		MET

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.95 Å
• R-Value Free:  0.240 (Depositor), 0.240 (DCC)
• R-Value Work:  0.219 (Depositor), 0.220 (DCC)
• R-Value Observed: 0.219 (Depositor)

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 42.72	α = 90
b = 71.874	β = 90
c = 94.438	γ = 90

Software Package:

Software Name	Purpose
CNS	refinement
CBASS	data collection
HKL-2000	data reduction
HKL-2000	data scaling
SHELXD	phasing
SHARP	phasing
ARP/wARP	model building

Structure Validation

Entry History

Deposition Data

• Released Date: 2007-08-28
Deposition Author(s): Palani, K., Kumaran, D., Burley, S.K., Swaminathan, S., New York SGX Research Center for Structural Genomics (NYSGXRC)

Revision History

• Version 1.0: 2007-08-28
  Type: Initial release

• Version 1.1: 2011-07-13
  Changes: Version format compliance
• Version 1.2: 2021-02-03
  Changes: Database references, Derived calculations, Structure summary
• Version 1.3: 2024-11-13
  Changes: Data collection, Database references, Structure summary
