2QVS

Crystal Structure of Type IIa Holoenzyme of cAMP-dependent Protein Kinase

Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.50 Å
  • R-Value Free: 0.251
  • R-Value Work: 0.212

wwPDB Validation   3D Report Full Report


This is version 1.1 of the entry. See complete history.


Literature

PKA type IIalpha holoenzyme reveals a combinatorial strategy for isoform diversity.

Wu, J., Brown, S.H.J., von Daake, S., Taylor, S.S.

(2007) Science 318: 274-279

  • DOI: 10.1126/science.1146447
  • Primary Citation of Related Structures:
    2QVS

  • PubMed Abstract:

    • The catalytic (C) subunit of cyclic adenosine monophosphate (cAMP)-dependent protein kinase (PKA) is inhibited by two classes of regulatory subunits, RI and RII. The RII subunits are substrates as well as inhibitors and do not require adenosine triphosphate (ATP) to form holoenzyme, which distinguishes them from RI subunits ...

    The catalytic (C) subunit of cyclic adenosine monophosphate (cAMP)-dependent protein kinase (PKA) is inhibited by two classes of regulatory subunits, RI and RII. The RII subunits are substrates as well as inhibitors and do not require adenosine triphosphate (ATP) to form holoenzyme, which distinguishes them from RI subunits. To understand the molecular basis for isoform diversity, we solved the crystal structure of an RIIalpha holoenzyme and compared it to the RIalpha holoenzyme. Unphosphorylated RIIalpha(90-400), a deletion mutant, undergoes major conformational changes as both of the cAMP-binding domains wrap around the C subunit's large lobe. The hallmark of this conformational reorganization is the helix switch in domain A. The C subunit is in an open conformation, and its carboxyl-terminal tail is disordered. This structure demonstrates the conserved and isoform-specific features of RI and RII and the importance of ATP, and also provides a new paradigm for designing isoform-specific activators or antagonists for PKA.

    Organizational Affiliation:

    Department of Chemistry and Biochemistry, University of California, San Diego, La Jolla, CA 92093, USA.



Macromolecules
Find similar proteins by:
(by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
cAMP-dependent protein kinase, alpha-catalytic subunitA [auth E]350Mus musculusMutation(s): 0
Gene Names: Prkaca, Pkaca
EC: 2.7.11.11
UniProt
Find proteins for P05132 (Mus musculus)
Explore P05132
Go to UniProtKB:  P05132
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP05132
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:
(by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChainsSequence LengthOrganismDetailsImage
cAMP-dependent protein kinase type II-alpha regulatory subunitB310Mus musculusMutation(s): 0
Gene Names: Prkar2a
UniProt
Find proteins for P12367 (Mus musculus)
Explore P12367
Go to UniProtKB:  P12367
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP12367
Protein Feature View
Expand
  • Reference Sequence
Small Molecules
Modified Residues  2 Unique
IDChainsTypeFormula2D DiagramParent
SEP
Query on SEP		A [auth E]L-PEPTIDE LINKINGC3 H8 N O6 PSER
TPO
Query on TPO		A [auth E]L-PEPTIDE LINKINGC4 H10 N O6 PTHR
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.50 Å
  • R-Value Free: 0.251
  • R-Value Work: 0.212
  • Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 87.9α = 90
b = 92.9β = 90
c = 118γ = 90
Software Package:
Software NamePurpose
ADSCdata collection
AMoREphasing
CNSrefinement
HKL-2000data reduction
HKL-2000data scaling

Structure Validation

View Full Validation Report



View more in-depth experimental data

Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2007-10-23
    Type: Initial release
  • Version 1.1: 2011-07-13
    Changes: Version format compliance
