2QTQ

Crystal structure of a predicted dna-binding transcriptional regulator (saro_1072) from novosphingobium aromaticivorans dsm at 1.85 A resolution

PDB DOI: https://doi.org/10.2210/pdb2QTQ/pdb

Classification: TRANSCRIPTION
Organism(s): Novosphingobium aromaticivorans DSM 12444
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2007-08-02 Released: 2007-08-21
Deposition Author(s): Joint Center for Structural Genomics (JCSG)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.85 Å
R-Value Free: 0.216
R-Value Work: 0.185
R-Value Observed: 0.186

wwPDB Validation 3D Report Full Report

This is version 1.4 of the entry. See complete history.

Literature

Crystal structure of predicted DNA-binding transcriptional regulator (YP_496351.1) from Novosphingobium aromaticivorans DSM 12444 at 1.85 A resolution

Joint Center for Structural Genomics (JCSG)

To be published.

Macromolecule Content

Total Structure Weight: 99.62 kDa
Atom Count: 7,418
Modelled Residue Count: 796
Deposited Residue Count: 852
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Transcriptional regulator, TetR family	A, B, C, D	213	Novosphingobium aromaticivorans DSM 12444	Mutation(s): 0 Gene Names: YP_496351.1, Saro_1072
UniProt
Find proteins for Q2G9F6 (Novosphingobium aromaticivorans (strain ATCC 700278 / DSM 12444 / CCUG 56034 / CIP 105152 / NBRC 16084 / F199)) Explore Q2G9F6 Go to UniProtKB: Q2G9F6
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	Q2G9F6
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
EDO Query on EDO Download Ideal Coordinates CCD File SDF format, chain AA [auth C] SDF format, chain BA [auth D] SDF format, chain CA [auth D] SDF format, chain DA [auth D] SDF format, chain EA [auth D] SDF format, chain F [auth A] SDF format, chain G [auth A] SDF format, chain H [auth A] SDF format, chain I [auth A] SDF format, chain J [auth A] SDF format, chain K [auth A] SDF format, chain L [auth A] SDF format, chain M [auth A] SDF format, chain N [auth A] SDF format, chain O [auth A] SDF format, chain Q [auth B] SDF format, chain R [auth B] SDF format, chain S [auth B] SDF format, chain T [auth B] SDF format, chain U [auth B] SDF format, chain V [auth B] SDF format, chain W [auth B] SDF format, chain Y [auth C] SDF format, chain Z [auth C] MOL2 format, chain AA [auth C] MOL2 format, chain BA [auth D] MOL2 format, chain CA [auth D] MOL2 format, chain DA [auth D] MOL2 format, chain EA [auth D] MOL2 format, chain F [auth A] MOL2 format, chain G [auth A] MOL2 format, chain H [auth A] MOL2 format, chain I [auth A] MOL2 format, chain J [auth A] MOL2 format, chain K [auth A] MOL2 format, chain L [auth A] MOL2 format, chain M [auth A] MOL2 format, chain N [auth A] MOL2 format, chain O [auth A] MOL2 format, chain Q [auth B] MOL2 format, chain R [auth B] MOL2 format, chain S [auth B] MOL2 format, chain T [auth B] MOL2 format, chain U [auth B] MOL2 format, chain V [auth B] MOL2 format, chain W [auth B] MOL2 format, chain Y [auth C] MOL2 format, chain Z [auth C]	AA [auth C] BA [auth D] CA [auth D] DA [auth D] EA [auth D] AA [auth C], BA [auth D], CA [auth D], DA [auth D], EA [auth D], F [auth A], G [auth A], H [auth A], I [auth A], J [auth A], K [auth A], L [auth A], M [auth A], N [auth A], O [auth A], Q [auth B], R [auth B], S [auth B], T [auth B], U [auth B], V [auth B], W [auth B], Y [auth C], Z [auth C]	1,2-ETHANEDIOL C₂ H₆ O₂ LYCAIKOWRPUZTN-UHFFFAOYSA-N		Interactions Focus chain AA [auth C] Focus chain BA [auth D] Focus chain CA [auth D] Focus chain DA [auth D] Focus chain EA [auth D] Focus chain F [auth A] Focus chain G [auth A] Focus chain H [auth A] Focus chain I [auth A] Focus chain J [auth A] Focus chain K [auth A] Focus chain L [auth A] Focus chain M [auth A] Focus chain N [auth A] Focus chain O [auth A] Focus chain Q [auth B] Focus chain R [auth B] Focus chain S [auth B] Focus chain T [auth B] Focus chain U [auth B] Focus chain V [auth B] Focus chain W [auth B] Focus chain Y [auth C] Focus chain Z [auth C] Interactions & Density Focus chain AA [auth C] Focus chain BA [auth D] Focus chain CA [auth D] Focus chain DA [auth D] Focus chain EA [auth D] Focus chain F [auth A] Focus chain G [auth A] Focus chain H [auth A] Focus chain I [auth A] Focus chain J [auth A] Focus chain K [auth A] Focus chain L [auth A] Focus chain M [auth A] Focus chain N [auth A] Focus chain O [auth A] Focus chain Q [auth B] Focus chain R [auth B] Focus chain S [auth B] Focus chain T [auth B] Focus chain U [auth B] Focus chain V [auth B] Focus chain W [auth B] Focus chain Y [auth C] Focus chain Z [auth C]
NO3 Query on NO3 Download Ideal Coordinates CCD File SDF format, chain E [auth A] SDF format, chain P [auth B] SDF format, chain X [auth C] MOL2 format, chain E [auth A] MOL2 format, chain P [auth B] MOL2 format, chain X [auth C]	E [auth A], P [auth B], X [auth C]	NITRATE ION N O₃ NHNBFGGVMKEFGY-UHFFFAOYSA-N		Interactions Focus chain E [auth A] Focus chain P [auth B] Focus chain X [auth C] Interactions & Density Focus chain E [auth A] Focus chain P [auth B] Focus chain X [auth C]

Modified Residues 1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE Query on MSE	A, B, C, D	L-PEPTIDE LINKING	C₅ H₁₁ N O₂ Se		MET

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.85 Å
R-Value Free: 0.216
R-Value Work: 0.185
R-Value Observed: 0.186
Space Group: P 2₁ 2₁ 2₁
Diffraction Data: https://doi.org/10.18430/M32QTQ

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 66.465	α = 90
b = 98.762	β = 90
c = 164.039	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
PHENIX	refinement
SHARP	phasing
MolProbity	model building
SCALA	data scaling
PDB_EXTRACT	data extraction
MAR345	data collection
MOSFLM	data reduction

Structure Validation

View Full Validation Report

Entry History

Deposition Data

Released Date: 2007-08-21

Deposition Author(s):

Joint Center for Structural Genomics (JCSG)

Revision History (Full details and data files)

Version 1.0: 2007-08-21
Type: Initial release
Version 1.1: 2011-07-13
Changes: Advisory, Source and taxonomy, Version format compliance
Version 1.2: 2017-10-25
Changes: Author supporting evidence, Refinement description
Version 1.3: 2019-07-24
Changes: Data collection, Derived calculations, Refinement description
Version 1.4: 2023-01-25
Changes: Database references, Derived calculations
