2PJ8

CRYSTAL STRUCTURE OF ACTIVATED PORCINE PANCREATIC CARBOXYPEPTIDASE B 2-(3-Aminomethyl-phenyl)-3-{[(R)-1-(biphenyl-4-sulfonylamino)-2-methyl-propyl]-hydroxy-phosphinoyl}-propionic acid COMPLEX


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.7 Å
  • R-Value Free: 0.200
  • R-Value Work: 0.176

wwPDB Validation 3D Report Full Report


This is version 1.1 of the entry. See complete history

Literature

Structures of potent selective peptide mimetics bound to carboxypeptidase B.

Adler, M.Buckman, B.Bryant, J.Chang, Z.Chu, K.Emayan, K.Hrvatin, P.Islam, I.Morser, J.Sukovich, D.West, C.Yuan, S.Whitlow, M.

(2008) Acta Crystallogr.,Sect.D 64: 149-157

  • DOI: 10.1107/S0907444907057228
  • Primary Citation of Related Structures:  2PIY, 2PIZ, 2PJ0, 2PJ1, 2PJ2, 2PJ3, 2PJ4, 2PJ5, 2PJ6, 2PJ7, 2PJ9, 2PJA, 2PJB, 2PJC

  • PubMed Abstract:
  • This article reports the crystal structures of inhibitors of the functional form of thrombin-activatable fibrinolysis inhibitor (TAFIa). In vivo experiments indicate that selective inhibitors of TAFIa would be useful in the treatment of heart attacks ...

    This article reports the crystal structures of inhibitors of the functional form of thrombin-activatable fibrinolysis inhibitor (TAFIa). In vivo experiments indicate that selective inhibitors of TAFIa would be useful in the treatment of heart attacks. Since TAFIa rapidly degrades in solution, the homologous protein porcine pancreatic carboxypeptidase B (pp-CpB) was used in these crystallography studies. Both TAFIa and pp-CpB are zinc-based exopeptidases that are specific for basic residues. The final development candidate, BX 528, is a potent inhibitor of TAFIa (2 nM) and has almost no measurable effect on the major selectivity target, carboxypeptidase N. BX 528 was designed to mimic the tripeptide Phe-Val-Lys. A sulfonamide replaces the Phe-Val amide bond and a phosphinate connects the Val and Lys groups. The phosphinate also chelates the active-site zinc. The electrostatic interactions with the protein mimic those of the natural substrate. The primary amine in BX 528 forms a salt bridge to Asp255 at the base of the S1' pocket. The carboxylic acid interacts with Arg145 and the sulfonamide is hydrogen bonded to Arg71. Isopropyl and phenyl groups replace the side chains of Val and Phe, respectively. A series of structures are presented here that illustrate the evolution of BX 528 from thiol-based inhibitors that mimic a free C-terminal arginine. The first step in development was the replacement of the thiol with a phosphinate. This caused a precipitous drop in binding affinity. Potency was reclaimed by extending the inhibitors into the downstream binding sites for the natural substrate.


    Related Citations:
    • 3-Mercaptopropionic acids as efficacious inhibitors of activated thrombin activatable fibrinolysis inhibitor (TAFIa).
      Islam, I.,Bryant, J.,May, K.,Mohan, R.,Yuan, S.,Kent, L.,Morser, J.,Zhao, L.,Vergona, R.,White, K.,Adler, M.,Whitlow, M.,Buckman, B.O.
      (2007) Bioorg.Med.Chem.Lett. 17: 1349
    • Crystal Structures of Potent Thiol-Based Inhibitors Bound to Carboxypeptidase B.
      Adler, M.,Bryant, J.,Buckman, B.,Islam, I.,Larsen, B.,Finster, S.,Kent, L.,May, K.,Mohan, R.,Yuan, S.,Whitlow, M.
      (2005) Biochemistry 44: 9339


    Organizational Affiliation

    Bayer HealthCare Pharmaceuticals, 2600 Hilltop Drive, PO Box 4099, Richmond, California 94804-0099, USA.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
Carboxypeptidase B
A, B, C
306Sus scrofaGene Names: CPB1 (CPB)
EC: 3.4.17.2
Find proteins for P09955 (Sus scrofa)
Go to Gene View: CPB1
Go to UniProtKB:  P09955
Small Molecules
Ligands 2 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
17A
Query on 17A

Download SDF File
Download CCD File
A, B, C
(2S)-2-[3-(AMINOMETHYL)PHENYL]-3-[(R)-{(1R)-1-[(BIPHENYL-4-YLSULFONYL)AMINO]-2-METHYLPROPYL}(HYDROXY)PHOSPHORYL]PROPANOIC ACID
C26 H31 N2 O6 P S
KEOUUUFVAPIYKJ-LOSJGSFVSA-N
 Ligand Interaction
ZN
Query on ZN

Download SDF File
Download CCD File
A, B, C
ZINC ION
Zn
PTFCDOFLOPIGGS-UHFFFAOYSA-N
 Ligand Interaction
External Ligand Annotations
IDBinding Affinity (Sequence Identity %)
17AIC50: 18 nM BINDINGMOAD
17AIC50: 18 nM PDBBIND
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.7 Å
  • R-Value Free: 0.200
  • R-Value Work: 0.176
  • Space Group: P 21 21 21
Unit Cell:
Length (Å)Angle (°)
a = 66.588α = 90.00
b = 95.472β = 90.00
c = 135.819γ = 90.00
Software Package:
Software NamePurpose
X-GENdata scaling
CNXrefinement
X-PLORmodel building
X-GENdata reduction
X-PLORphasing

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

  • Deposited Date: 2007-04-15
  • Released Date: 2008-01-22
  • Deposition Author(s): Adler, M., Whitlow, M.

Revision History

  • Version 1.0: 2008-01-22
    Type: Initial release
  • Version 1.1: 2011-07-13
    Type: Version format compliance
