2OTX

Crystal Structure of A N-terminal Fragment of SKAP-HOM Containing both the Helical Dimerization Domain and the PH Domain


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.60 Å
  • R-Value Free: 0.216
  • R-Value Work: 0.179
  • R-Value Observed: 0.181

wwPDB Validation   3D Report Full Report


This is version 1.4 of the entry. See complete history


Literature

The Skap-hom dimerization and PH domains comprise a 3'-phosphoinositide-gated molecular switch.

Swanson, K.D.Tang, Y.Ceccarelli, D.F.Poy, F.Sliwa, J.P.Neel, B.G.Eck, M.J.

(2008) Mol Cell 32: 564-575

  • DOI: https://doi.org/10.1016/j.molcel.2008.09.022
  • Primary Citation of Related Structures:
    1U5G, 2OTX

  • PubMed Abstract:

    PH domains, by binding to phosphoinositides, often serve as membrane-targeting modules. Using crystallographic, biochemical, and cell biological approaches, we have uncovered a mechanism that the integrin-signaling adaptor Skap-hom uses to mediate cytoskeletal interactions. Skap-hom is a homodimer containing an N-terminal four-helix bundle dimerization domain, against which its two PH domains pack in a conformation incompatible with phosphoinositide binding. The isolated PH domains bind PI[3,4,5]P(3), and mutations targeting the dimerization domain or the PH domain's PI[3,4,5]P(3)-binding pocket prevent Skap-hom localization to ruffles. Targeting is retained when the PH domain is deleted or by combined mutation of the PI[3,4,5]P(3)-binding pocket and the PH/dimerization domain interface. Thus, the dimerization and PH domain form a PI[3,4,5]P(3)-responsive molecular switch that controls Skap-hom function.


  • Organizational Affiliation

    Cancer Biology Program, Division of Hematology-Oncology, Department of Medicine, Beth Israel Deaconess Medical Center, Boston, MA 02115, USA.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Src kinase-associated phosphoprotein 2
A, B
211Mus musculusMutation(s): 2
Gene Names: Skap2PrapRa70SapsScap2Skap55r
UniProt
Find proteins for Q3UND0 (Mus musculus)
Explore Q3UND0
Go to UniProtKB:  Q3UND0
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ3UND0
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.60 Å
  • R-Value Free: 0.216
  • R-Value Work: 0.179
  • R-Value Observed: 0.181
  • Space Group: C 1 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 106.205α = 90
b = 56.742β = 95.82
c = 89.115γ = 90
Software Package:
Software NamePurpose
AMoREphasing
REFMACrefinement
DENZOdata reduction
SCALEPACKdata scaling

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2007-03-27
    Type: Initial release
  • Version 1.1: 2008-05-01
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Version format compliance
  • Version 1.3: 2021-10-20
    Changes: Database references
  • Version 1.4: 2023-08-30
    Changes: Data collection, Refinement description
