2OND

Crystal Structure of the HAT-C domain of murine CstF-77


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.80 Å
  • R-Value Free: 0.262
  • R-Value Work: 0.224
  • R-Value Observed: 0.224

wwPDB Validation   3D Report Full Report


This is version 1.5 of the entry. See complete history


Literature

Crystal Structure of Murine CstF-77: Dimeric Association and Implications for Polyadenylation of mRNA Precursors.

Bai, Y.Auperin, T.C.Chou, C.Y.Chang, G.G.Manley, J.L.Tong, L.

(2007) Mol Cell 25: 863-875

  • DOI: https://doi.org/10.1016/j.molcel.2007.01.034
  • Primary Citation of Related Structures:
    2OND, 2OOE

  • PubMed Abstract:

    Cleavage stimulation factor (CstF) is a heterotrimeric protein complex essential for polyadenylation of mRNA precursors. The 77 kDa subunit, CstF-77, is known to mediate interactions with the other two subunits of CstF as well as with other components of the polyadenylation machinery. We report here the crystal structure of the HAT (half a TPR) domain of murine CstF-77, as well as its C-terminal subdomain. Structural and biochemical studies show that the HAT domain consists of two subdomains, HAT-N and HAT-C domains, with drastically different orientations of their helical motifs. The structures reveal a highly elongated dimer, spanning 165 A, with the dimerization mediated by the HAT-C domain. Light-scattering studies, yeast two-hybrid assays, and analytical ultracentrifugation measurements confirm this self-association. The mode of dimerization and the relative arrangement of the HAT-N and HAT-C domains are unique to CstF-77. Our data support a role for CstF dimerization in pre-mRNA 3' end processing.


  • Organizational Affiliation

    Department of Biological Sciences, Columbia University, New York, NY 10027, USA.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Cleavage stimulation factor 77 kDa subunit
A, B
308Mus musculusMutation(s): 9
Gene Names: Cstf3
UniProt & NIH Common Fund Data Resources
Find proteins for Q99LI7 (Mus musculus)
Explore Q99LI7
Go to UniProtKB:  Q99LI7
IMPC:  MGI:1351825
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ99LI7
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Modified Residues  1 Unique
IDChains TypeFormula2D DiagramParent
MSE
Query on MSE
A, B
L-PEPTIDE LINKINGC5 H11 N O2 SeMET
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.80 Å
  • R-Value Free: 0.262
  • R-Value Work: 0.224
  • R-Value Observed: 0.224
  • Space Group: P 61 2 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 155.4α = 90
b = 155.4β = 90
c = 161.6γ = 120
Software Package:
Software NamePurpose
SnBphasing
CNSrefinement
ADSCdata collection
DENZOdata reduction
SCALEPACKdata scaling
SOLVEphasing
RESOLVEphasing

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2007-04-10
    Type: Initial release
  • Version 1.1: 2008-05-01
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Version format compliance
  • Version 1.3: 2017-10-18
    Changes: Refinement description
  • Version 1.4: 2023-12-27
    Changes: Data collection, Database references, Derived calculations
  • Version 1.5: 2024-10-30
    Changes: Structure summary
