2NZ1

Viral Chemokine Binding Protein M3 From Murine Gammaherpesvirus68 In Complex With The CC-Chemokine CCL2/MCP-1


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.50 Å
  • R-Value Free: 0.300
  • R-Value Work: 0.231
  • R-Value Observed: 0.231

wwPDB Validation   3D Report Full Report


This is version 1.3 of the entry. See complete history


Literature

Dual GPCR and GAG mimicry by the M3 chemokine decoy receptor.

Alexander-Brett, J.M.Fremont, D.H.

(2007) J Exp Med 204: 3157-3172

  • DOI: https://doi.org/10.1084/jem.20071677
  • Primary Citation of Related Structures:
    2NYZ, 2NZ1

  • PubMed Abstract:

    Viruses have evolved a myriad of evasion strategies focused on undermining chemokine-mediated immune surveillance, exemplified by the mouse gamma-herpesvirus 68 M3 decoy receptor. Crystal structures of M3 in complex with C chemokine ligand 1/lymphotactin and CC chemokine ligand 2/monocyte chemoattractant protein 1 reveal that invariant chemokine features associated with G protein-coupled receptor binding are primarily recognized by the decoy C-terminal domain, whereas the N-terminal domain (NTD) reconfigures to engage divergent basic residue clusters on the surface of chemokines. Favorable electrostatic forces dramatically enhance the association kinetics of chemokine binding by M3, with a primary role ascribed to acidic NTD regions that effectively mimic glycosaminoglycan interactions. Thus, M3 employs two distinct mechanisms of chemical imitation to potently sequester chemokines, thereby inhibiting chemokine receptor binding events as well as the formation of chemotactic gradients necessary for directed leukocyte trafficking.


  • Organizational Affiliation

    Department of Pathology and Immunology, Washington University School of Medicine, St. Louis, MO 63110, USA.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Hypothetical protein GAMMAHV.M3A,
B,
E [auth X]
382Murid gammaherpesvirus 4Mutation(s): 0
Gene Names: GAMMAHV.M3M3
UniProt
Find proteins for O41925 (Murid herpesvirus 4)
Explore O41925
Go to UniProtKB:  O41925
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupO41925
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
Small inducible cytokine A2C [auth D],
D [auth E],
F [auth Y]
76Homo sapiensMutation(s): 1
Gene Names: CCL2MCP1SCYA2
UniProt & NIH Common Fund Data Resources
Find proteins for P13500 (Homo sapiens)
Explore P13500
Go to UniProtKB:  P13500
PHAROS:  P13500
GTEx:  ENSG00000108691
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP13500
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.50 Å
  • R-Value Free: 0.300
  • R-Value Work: 0.231
  • R-Value Observed: 0.231
  • Space Group: P 31 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 99.24α = 90
b = 99.24β = 90
c = 243.46γ = 120
Software Package:
Software NamePurpose
CNSrefinement
HKL-2000data collection
HKL-2000data reduction
SCALEPACKdata scaling
AMoREphasing

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2007-12-25
    Type: Initial release
  • Version 1.1: 2011-07-13
    Changes: Derived calculations, Version format compliance
  • Version 1.2: 2021-10-20
    Changes: Database references
  • Version 1.3: 2023-08-30
    Changes: Data collection, Refinement description
