Biological Assembly 1

 3D View: Structure | Electron Density | Ligand Interaction

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 assigned by authors and generated by PQS (software)

Biological Assembly 2

 3D View: Structure | Electron Density | Ligand Interaction

Global Symmetry: Cyclic - C2  (3D View)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 2 generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 20.74 kDa
• Atom Count: 1629
• Residue Count: 167
• Unique protein chains: 1

2NSA

Structures of and interactions between domains of trigger factor from Themotoga maritim

• DOI: 10.2210/pdb2NSA/pdb

• Classification: CHAPERONE
• Organism(s): Thermotoga maritima
• Expression System: Escherichia coli
• Mutation(s): Yes


• Deposited: 2006-11-03 Released: 2007-03-27
• Deposition Author(s): Martinez-Hackert, E., Hendrickson, W.A.

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.70 Å
• R-Value Free: 0.252
• R-Value Work: 0.227

Literature

Structures of and interactions between domains of trigger factor from Thermotoga maritima.

Martinez-Hackert, E., Hendrickson, W.A.

(2007) Acta Crystallogr D Biol Crystallogr 63: 536-547

• PubMed: 17372359
• DOI: 10.1107/S090744490700964X
• Structures With Same Primary Citation


• PubMed Abstract:


Trigger factor (TF) is a eubacterial chaperone that associates with ribosomes at the peptide-exit tunnel and also occurs in excess free in the cytosol. TF is a three-domain protein that appears to exist in a dynamic equilibrium of oligomerization states and interdomain conformations. X-ray crystallography and chemical cross-linking were used to study the roles of the N- and C-terminal domains of Thermotoga maritima TF in TF oligomerization and chaperone activity. The structural conservation of both the N- and C-terminal TF domains was unambiguously established. The biochemical and crystallographic data reveal a tendency for these domains to partake in diverse and apparently nonspecific protein-protein interactions. It is found that the T. maritima and Escherichia coli TF surfaces lack evident exposed hydrophobic patches. Taken together, these data suggest that TF chaperones could interact with nascent proteins via hydrophilic surfaces.

---

Organizational Affiliation:

Department of Biochemistry and Molecular Biophysics, Columbia University, New York, NY 10032, USA.

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details
Trigger factor	A	170	Thermotoga maritima	Mutation(s): 2  Gene Names: tig EC: 5.2.1.8
Find proteins for Q9WZF8 (Thermotoga maritima (strain ATCC 43589 / MSB8 / DSM 3109 / JCM 10099)) Go to UniProtKB:  Q9WZF8

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
SO4	A	SULFATE ION O4 S QAOWNCQODCNURD-UHFFFAOYSA-L

Modified Residues  1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE	A	L-PEPTIDE LINKING	C5 H11 N O2 Se		MET

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.70 Å
• R-Value Free: 0.252
• R-Value Work: 0.227
• Space Group: C 2 2 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 53.84	α = 90
b = 74.21	β = 90
c = 90.07	γ = 90

Software Package:

Software Name	Purpose
SOLVE	phasing
RESOLVE	phasing
CNS	refinement
PDB_EXTRACT	data extraction
ADSC	data collection
DENZO	data reduction
SCALEPACK	data scaling

Structure Validation

Entry History

Deposition Data

• Deposited Date: 2006-11-03
• Released Date: 2007-03-27
Deposition Author(s): Martinez-Hackert, E., Hendrickson, W.A.

Revision History

• Version 1.0: 2007-03-27
  Type: Initial release

• Version 1.1: 2008-05-01
  Changes: Version format compliance
• Version 1.2: 2011-07-13
  Changes: Derived calculations, Version format compliance
