2HAJ | pdb_00002haj

Solution structure of the helicase-binding domain of Escherichia coli primase


Experimental Data Snapshot

  • Method: SOLUTION NMR
  • Conformers Calculated: 200
  • Conformers Submitted: 20
  • Selection Criteria: structures with the least restraint violations

wwPDB Validation 3D Report Full Report

Validation slider image for 2HAJ

This is version 1.5 of the entry. See complete history

Literature

Monomeric solution structure of the helicase-binding domain of Escherichia coli DnaG primase

Su, X.C.Schaeffer, P.M.Loscha, K.V.Gan, P.H.P.Dixon, N.E.Otting, G.

(2006) FEBS J 273: 4997-5009

  • DOI: https://doi.org/10.1111/j.1742-4658.2006.05495.x
  • Primary Citation Related Structures:
    2HAJ

  • PubMed Abstract:

    DnaG is the primase that lays down RNA primers on single-stranded DNA during bacterial DNA replication. The solution structure of the DnaB-helicase-binding C-terminal domain of Escherichia coli DnaG was determined by NMR spectroscopy at near-neutral pH. The structure is a rare fold that, besides occurring in DnaG C-terminal domains, has been described only for the N-terminal domain of DnaB. The C-terminal helix hairpin present in the DnaG C-terminal domain, however, is either less stable or absent in DnaB, as evidenced by high mobility of the C-terminal 35 residues in a construct comprising residues 1-171. The present structure identifies the previous crystal structure of the E. coli DnaG C-terminal domain as a domain-swapped dimer. It is also significantly different from the NMR structure reported for the corresponding domain of DnaG from the thermophile Bacillus stearothermophilus. NMR experiments showed that the DnaG C-terminal domain does not bind to residues 1-171 of the E. coli DnaB helicase with significant affinity.


  • Organizational Affiliation
    • Research School of Chemistry, Australian National University, Canberra, ACT 0200, Australia.

Macromolecule Content

  • Total Structure Weight: 16.72 kDa
  • Atom Count: 1,081
  • Modeled Residue Count: 135
  • Deposited Residue Count: 148
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
DNA primase148Escherichia coliMutation(s): 0
Gene Names: dnaG
EC: 2.7.7 (PDB Primary Data), 2.7.7.101 (UniProt)
UniProt
Find proteins for P0ABS5 (Escherichia coli (strain K12))
Explore P0ABS5
Go to UniProtKB:  P0ABS5
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0ABS5
Sequence Annotations
Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

  • Method: SOLUTION NMR
  • Conformers Calculated: 200
  • Conformers Submitted: 20
  • Selection Criteria: structures with the least restraint violations

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2006-10-17
    Type: Initial release
  • Version 1.1: 2008-05-01
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Version format compliance
  • Version 1.3: 2020-02-26
    Changes: Data collection, Database references, Derived calculations, Other
  • Version 1.4: 2023-06-14
    Changes: Database references, Other
  • Version 1.5: 2024-05-15
    Changes: Data collection, Database references
