2H1T

Crystal structure of a duf1089 family protein (pa1994) from pseudomonas aeruginosa at 1.80 A resolution


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.80 Å
  • R-Value Free: 0.213
  • R-Value Work: 0.170
  • R-Value Observed: 0.172

wwPDB Validation   3D Report Full Report


This is version 1.4 of the entry. See complete history


Literature

The structure of the first representative of Pfam family PF06475 reveals a new fold with possible involvement in glycolipid metabolism.

Bakolitsa, C.Kumar, A.McMullan, D.Krishna, S.S.Miller, M.D.Carlton, D.Najmanovich, R.Abdubek, P.Astakhova, T.Chiu, H.J.Clayton, T.Deller, M.C.Duan, L.Elias, Y.Feuerhelm, J.Grant, J.C.Grzechnik, S.K.Han, G.W.Jaroszewski, L.Jin, K.K.Klock, H.E.Knuth, M.W.Kozbial, P.Marciano, D.Morse, A.T.Nigoghossian, E.Okach, L.Oommachen, S.Paulsen, J.Reyes, R.Rife, C.L.Trout, C.V.van den Bedem, H.Weekes, D.White, A.Xu, Q.Hodgson, K.O.Wooley, J.Elsliger, M.A.Deacon, A.M.Godzik, A.Lesley, S.A.Wilson, I.A.

(2010) Acta Crystallogr Sect F Struct Biol Cryst Commun 66: 1211-1217

  • DOI: https://doi.org/10.1107/S1744309109022684
  • Primary Citation of Related Structures:
    2H1T

  • PubMed Abstract:

    The crystal structure of PA1994 from Pseudomonas aeruginosa, a member of the Pfam PF06475 family classified as a domain of unknown function (DUF1089), reveals a novel fold comprising a 15-stranded β-sheet wrapped around a single α-helix that assembles into a tight dimeric arrangement. The remote structural similarity to lipoprotein localization factors, in addition to the presence of an acidic pocket that is conserved in DUF1089 homologs, phospholipid-binding and sugar-binding proteins, indicate a role for PA1994 and the DUF1089 family in glycolipid metabolism. Genome-context analysis lends further support to the involvement of this family of proteins in glycolipid metabolism and indicates possible activation of DUF1089 homologs under conditions of bacterial cell-wall stress or host-pathogen interactions.


  • Organizational Affiliation

    Stanford Synchrotron Radiation Lightsource, SLAC National Accelerator Laboratory, Menlo Park, CA, USA.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Hypothetical protein
A, B
188Pseudomonas aeruginosaMutation(s): 2
Gene Names: NP_250684.1
UniProt
Find proteins for Q9I2B5 (Pseudomonas aeruginosa (strain ATCC 15692 / DSM 22644 / CIP 104116 / JCM 14847 / LMG 12228 / 1C / PRS 101 / PAO1))
Explore Q9I2B5
Go to UniProtKB:  Q9I2B5
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ9I2B5
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 2 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
MPD
Query on MPD

Download Ideal Coordinates CCD File
F [auth A],
M [auth B]
(4S)-2-METHYL-2,4-PENTANEDIOL
C6 H14 O2
SVTBMSDMJJWYQN-YFKPBYRVSA-N
EDO
Query on EDO

Download Ideal Coordinates CCD File
C [auth A]
D [auth A]
E [auth A]
G [auth B]
H [auth B]
C [auth A],
D [auth A],
E [auth A],
G [auth B],
H [auth B],
I [auth B],
J [auth B],
K [auth B],
L [auth B]
1,2-ETHANEDIOL
C2 H6 O2
LYCAIKOWRPUZTN-UHFFFAOYSA-N
Modified Residues  1 Unique
IDChains TypeFormula2D DiagramParent
MSE
Query on MSE
A, B
L-PEPTIDE LINKINGC5 H11 N O2 SeMET
Experimental Data & Validation

Experimental Data

Unit Cell:
Length ( Å )Angle ( ˚ )
a = 130.03α = 90
b = 41.9β = 91.22
c = 78.65γ = 90
Software Package:
Software NamePurpose
MolProbitymodel building
REFMACrefinement
XSCALEdata scaling
PDB_EXTRACTdata extraction
XDSdata reduction
SHARPphasing

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2006-05-30
    Type: Initial release
  • Version 1.1: 2008-05-01
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Advisory, Version format compliance
  • Version 1.3: 2017-10-18
    Changes: Refinement description
  • Version 1.4: 2023-01-25
    Changes: Database references, Derived calculations
