2F19

THREE-DIMENSIONAL STRUCTURE OF TWO CRYSTAL FORMS OF FAB R19.9, FROM A MONOCLONAL ANTI-ARSONATE ANTIBODY


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.8 Å
  • R-Value Work: 0.182

wwPDB Validation 3D Report Full Report


This is version 1.2 of the entry. See complete history

Literature

Three-dimensional structure of two crystal forms of FabR19.9 from a monoclonal anti-arsonate antibody.

Lascombe, M.-B.Alzari, P.M.Poljak, R.J.Nisonoff, A.

(1992) Proc.Natl.Acad.Sci.USA 89: 9429-9433

  • Primary Citation of Related Structures:

  • PubMed Abstract:
  • The three-dimensional structure of FabR19.9 from a well-characterized anti-p-azobenzenearsonate monoclonal antibody has been determined by x-ray diffraction techniques in two crystalline forms (I and II) to a resolution of 2.8 and 2.7 A, respectively ...

    The three-dimensional structure of FabR19.9 from a well-characterized anti-p-azobenzenearsonate monoclonal antibody has been determined by x-ray diffraction techniques in two crystalline forms (I and II) to a resolution of 2.8 and 2.7 A, respectively. Essentially the same tertiary and quaternary structure of the Fab is observed in the two forms. The major difference resides in the intermolecular contacts, which are interpreted to favor an irreversible transition from the metastable form I to the more stable form II. The third complementarity-determining region of the heavy chain (H3) folds back over the combining site and requires rearrangement for hapten binding. This dynamic requirement on H3 is consistent with its mobility in the structure and can explain hapten binding to an otherwise inaccessible antibody combining site.


    Related Citations:
    • Crystallization of the Fab Fragments of Monoclonal Anti-P-Azophenylarsonate Antibodies and Their Complexes with Haptens
      Mariuzza, R.A.,Amit, A.G.,Boulot, G.,Saludjian, P.,Saul, F.A.,Tougard, P.,Poljak, R.J.,Conger, J.,Lamoyi, E.,Nisonoff, A.
      (1984) J.Biol.Chem. 259: 5954
    • Three-Dimensional Structure of Fab R19.9, A Monoclonal Murine Antibody Specific for the P-Azobenzenearsonate Group
      Lascombe, M.B.,Alzari, P.M.,Boulot, G.,Saludjian, P.,Tougard, P.,Berek, C.,Haba, S.,Rosen, E.M.,Nisonoff, A.,Poljak, R.J.
      (1989) Proc.Natl.Acad.Sci.USA 86: 607


    Organizational Affiliation

    Unite de Recherche AssociƩe 359 Centre National de la Recherche Scientifique, Institut Pasteur, Paris, France.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
IGG2B-KAPPA R19.9 FAB (LIGHT CHAIN)
L
214Mus musculusMutation(s): 0
Gene Names: Igkc
Find proteins for P01837 (Mus musculus)
Go to UniProtKB:  P01837
Entity ID: 2
MoleculeChainsSequence LengthOrganismDetails
IGG2B-KAPPA R19.9 FAB (HEAVY CHAIN)
H
221N/AMutation(s): 0
Protein Feature View is not available: No corresponding UniProt sequence found.
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.8 Å
  • R-Value Work: 0.182
  • Space Group: P 1 21 1
Unit Cell:
Length (Å)Angle (°)
a = 43.300α = 90.00
b = 80.800β = 96.00
c = 75.100γ = 90.00
Software Package:
Software NamePurpose
X-PLORrefinement

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 1992-10-15
    Type: Initial release
  • Version 1.1: 2008-03-24
    Type: Version format compliance
  • Version 1.2: 2011-07-13
    Type: Version format compliance
