2ER9

X-RAY STUDIES OF ASPARTIC PROTEINASE-STATINE INHIBITOR COMPLEXES.


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.20 Å
  • R-Value Work: 0.170

wwPDB Validation   3D Report Full Report


This is version 1.4 of the entry. See complete history


Literature

X-ray studies of aspartic proteinase-statine inhibitor complexes.

Cooper, J.B.Foundling, S.I.Blundell, T.L.Boger, J.Jupp, R.A.Kay, J.

(1989) Biochemistry 28: 8596-8603

  • DOI: 10.1021/bi00447a049
  • Primary Citation of Related Structures:
    2ER0, 2ER9

  • PubMed Abstract:
  • The conformation of a statine-containing renin inhibitor complexed with the aspartic proteinase from the fungus Endothia parasitica (EC 3.4.23.6) has been determined by X-ray diffraction at 2.2-A resolution (R = 0.17). We describe the structure of the complex at high resolution and compare this with a 3 ...

    The conformation of a statine-containing renin inhibitor complexed with the aspartic proteinase from the fungus Endothia parasitica (EC 3.4.23.6) has been determined by X-ray diffraction at 2.2-A resolution (R = 0.17). We describe the structure of the complex at high resolution and compare this with a 3.0-A resolution analysis of a bound inhibitor, L-364,099, containing a cyclohexylalanine analogue of statine. The inhibitors bind in extended conformations in the long active-site cleft, and the hydroxyl of the transition-state analogue, statine, interacts strongly with the catalytic aspartates via hydrogen bonds to the essential carboxyl groups. This work provides a detailed structural analysis of the role of statine in peptide inhibitors. It shows conclusively that statine should be considered a dipeptide analogue (occupying P1 to P1') despite lacking the equivalent of a P1' side chain, although other inhibitor residues (especially P2) may compensate by interacting at the unoccupied S1' specificity subsite.


    Related Citations:
    • The Active Site of Aspartic Proteinases
      Pearl, L., Blundell, T.
      (1984) FEBS Lett 174: 96
    • Active Site of Acid Proteinases
      Blundell, T.L., Jones, H.B., Khan, G., Taylor, G., Sewell, T.S., Pearl, L.H., Wood, S.P.
      (1979) Proc Febs Meet 60: 281
    • The Three-Dimensional Structure of Acid Proteinases
      Blundell, T.L., Jenkins, J.A., Khan, G., Roychowdhury, P., Sewell, T., Tickle, I.J., Wood, E.A.
      (1979) Proc Febs Meet 52: 81
    • Four-Fold Structural Repeat in the Acid Proteases
      Blundell, T.L., Sewell, B.T., Mclachlan, A.D.
      (1979) Biochim Biophys Acta 580: 24
    • Structural Evidence for Gene Duplication in the Evolution of Acid Proteases
      Tang, J., James, M.N.G., Hsu, I.N., Jenkins, J.A., Blundell, T.L.
      (1978) Nature 271: 618
    • Homology Among Acid Proteases. Comparison of Crystal Structures at 3 Angstroms Resolution of Acid Proteases from Rhizopus Chinensis and Endothia Parasitica
      Subramanian, E., Swan, I.D.A., Liu, M., Davies, D.R., Jenkins, J.A., Tickle, I.J., Blundell, T.L.
      (1977) Proc Natl Acad Sci U S A 74: 556
    • X-Ray Analysis and Circular Dichroism of the Acid Protease from Endothia Parasitica and Chymosin
      Jenkins, J., Tickle, I., Sewell, T., Ungaretti, L., Wollmer, A., Blundell, T.
      (1977) Adv Exp Med Biol 95: 43

    Organizational Affiliation

    Department of Crystallography, Birkbeck College, London, U.K.



Macromolecules
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
ENDOTHIAPEPSINA [auth E]330Cryphonectria parasiticaMutation(s): 0
Gene Names: EAPAEPN-1
EC: 3.4.23.6 (PDB Primary Data), 3.4.23.22 (UniProt)
UniProt
Find proteins for P11838 (Cryphonectria parasitica)
Explore P11838
Go to UniProtKB:  P11838
Protein Feature View
Expand
  • Reference Sequence
  • Find similar proteins by:  Sequence   |   Structure
Entity ID: 2
MoleculeChainsSequence LengthOrganismDetailsImage
L363,564B [auth I]8N/AMutation(s): 0
Protein Feature View
Expand
  • Reference Sequence
Biologically Interesting Molecules (External Reference) 1 Unique
Entity ID: 2
IDChainsNameType/Class2D Diagram3D Interactions
PRD_000268
Query on PRD_000268
B [auth I]L-364,099Peptide-like /  Inhibitor Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.20 Å
  • R-Value Work: 0.170
  • Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 53.5α = 90
b = 73.9β = 109.1
c = 45.6γ = 90
Software Package:
Software NamePurpose
PROLSQrefinement

Structure Validation

View Full Validation Report




Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 1991-01-15
    Type: Initial release
  • Version 1.1: 2008-03-03
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Atomic model, Database references, Derived calculations, Non-polymer description, Structure summary, Version format compliance
  • Version 1.3: 2012-12-12
    Changes: Other
  • Version 1.4: 2017-11-29
    Changes: Derived calculations, Other
