2E33

Structural basis for selection of glycosylated substrate by SCFFbs1 ubiquitin ligase


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.70 Å
  • R-Value Free: 0.288
  • R-Value Work: 0.216
  • R-Value Observed: 0.220

wwPDB Validation 3D Report Full Report


This is version 1.3 of the entry. See complete history


Literature

Structural basis for the selection of glycosylated substrates by SCFFbs1 ubiquitin ligase

Mizushima, T.Yoshida, Y.Kumanomidou, T.Hasegawa, Y.Suzuki, A.Yamane, T.Tanaka, K.

(2007) Proc Natl Acad Sci U S A 104: 5777-5781

  • DOI: 10.1073/pnas.0610312104
  • Structures With Same Primary Citation

  • PubMed Abstract:
  • The ubiquitin ligase complex SCF(Fbs1), which contributes to the ubiquitination of glycoproteins, is involved in the endoplasmic reticulum-associated degradation pathway. In SCF ubiquitin ligases, a diverse array of F-box proteins confers substrate s ...

    The ubiquitin ligase complex SCF(Fbs1), which contributes to the ubiquitination of glycoproteins, is involved in the endoplasmic reticulum-associated degradation pathway. In SCF ubiquitin ligases, a diverse array of F-box proteins confers substrate specificity. Fbs1/Fbx2, a member of the F-box protein family, recognizes high-mannose oligosaccharides. To elucidate the structural basis of SCF(Fbs1) function, we determined the crystal structures of the Skp1-Fbs1 complex and the sugar-binding domain (SBD) of the Fbs1-glycoprotein complex. The mechanistic model indicated by the structures appears to be well conserved among the SCF ubiquitin ligases. The structure of the SBD-glycoprotein complex indicates that the SBD primarily recognizes Man(3)GlcNAc(2), thereby explaining the broad activity of the enzyme against various glycoproteins. Comparison of two crystal structures of the Skp1-Fbs1 complex revealed the relative motion of a linker segment between the F-box and the SBD domains, which might underlie the ability of the complex to recognize different acceptor lysine residues for ubiquitination.


    Organizational Affiliation

    Department of Biotechnology, Graduate School of Engineering, Nagoya University, Chikusa-ku, Nagoya 464-8603, Japan.



Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
F-box only protein 2
A
197Mus musculusMutation(s): 0
Gene Names: Fbxo2Fbs1Fbx2
Find proteins for Q80UW2 (Mus musculus)
Go to UniProtKB:  Q80UW2
NIH Common Fund Data Resources

Find similar proteins by: Sequence  |  Structure

Entity ID: 2
MoleculeChainsSequence LengthOrganismDetails
Ribonuclease pancreatic
B
124Bos taurusMutation(s): 0
Gene Names: RNASE1RNS1
EC: 3.1.27.5 (PDB Primary Data), 4.6.1.18 (UniProt)
Find proteins for P61823 (Bos taurus)
Go to UniProtKB:  P61823
Small Molecules
Ligands 3 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
NAG
Query on NAG

Download CCD File
B
N-ACETYL-D-GLUCOSAMINE
C8 H15 N O6
OVRNDRQMDRJTHS-FMDGEEDCSA-N
 Ligand Interaction
BMA
Query on BMA

Download CCD File
B
BETA-D-MANNOSE
C6 H12 O6
WQZGKKKJIJFFOK-RWOPYEJCSA-N
 Ligand Interaction
MAN
Query on MAN

Download CCD File
B
ALPHA-D-MANNOSE
C6 H12 O6
WQZGKKKJIJFFOK-PQMKYFCFSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.70 Å
  • R-Value Free: 0.288
  • R-Value Work: 0.216
  • R-Value Observed: 0.220
  • Space Group: P 4 3 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 148.314α = 90
b = 148.314β = 90
c = 148.314γ = 90
Software Package:
Software NamePurpose
REFMACrefinement
DENZOdata reduction
SCALEPACKdata scaling
MOLREPphasing

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History

  • Version 1.0: 2007-03-20
    Type: Initial release
  • Version 1.1: 2008-04-30
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Non-polymer description, Version format compliance
  • Version 1.3: 2014-02-26
    Changes: Derived calculations
