2B5R

1B Lactamase / B Lactamase Inhibitor


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.65 Å
  • R-Value Free: 0.222
  • R-Value Work: 0.190

wwPDB Validation 3D Report Full Report


This is version 1.4 of the entry. See complete history

Literature

Binding Hot Spots in the TEM1-BLIP Interface in Light of its Modular Architecture.

Reichmann, D.Cohen, M.Abramovich, R.Dym, O.Lim, D.Strynadka, N.C.Schreiber, G.

(2006) J.Mol.Biol. 102: 57-62

  • DOI: 10.1016/j.jmb.2006.09.076

  • PubMed Abstract:
  • Proteins bind one another in aqua's solution to form tight and specific complexes. Previously we have shown that this is achieved through the modular architecture of the interaction network formed by the interface residues, where tight cooperative in ...

    Proteins bind one another in aqua's solution to form tight and specific complexes. Previously we have shown that this is achieved through the modular architecture of the interaction network formed by the interface residues, where tight cooperative interactions are found within modules but not between them. Here we extend this study to cover the entire interface of TEM1 beta-lactamase and its protein inhibitor BLIP using an improved method for deriving interaction maps based on REDUCE to add hydrogen atoms and then by evaluating the interactions using modifications of the programs PROBE, NCI and PARE. An extensive mutagenesis study of the interface residues indeed showed that each module is energetically independent on other modules, and that cooperativity is found only within a module. By solving the X-ray structure of two interface mutations affecting two different modules, we demonstrated that protein-protein binding occur via the structural reorganization of the binding modules, either by a "lock and key" or an induced fit mechanism. To explain the cooperativity within a module, we performed multiple-mutant cycle analysis of cluster 2 resulting in a high-resolution energy map of this module. Mutant studies are usually done in reference to alanine, which can be regarded as a deletion of a side-chain. However, from a biological perspective, there is a major interest to understand non-Ala substitutions, as they are most common. Using X-ray crystallography and multiple-mutant cycle analysis we demonstrated the added complexity in understanding non-Ala mutations. Here, a double mutation replacing the wild-type Glu,Tyr to Tyr,Asn on TEM1 (res id 104,105) caused a major backbone structural rearrangement of BLIP, changing the composition of two modules but not of other modules within the interface. This shows the robustness of the modular approach, yet demonstrates the complexity of in silico protein design.


    Organizational Affiliation

    Department of Biological Chemistry, Weizmann Institute of Science, Rehovot 76100, Israel.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
Beta-lactamase TEM
A, B
263Escherichia coliMutation(s): 3
Gene Names: bla, blaT-3, blaT-4, blaT-5, blaT-6
EC: 3.5.2.6
Find proteins for P62593 (Escherichia coli)
Go to UniProtKB:  P62593
Entity ID: 2
MoleculeChainsSequence LengthOrganismDetails
Beta-lactamase inhibitory protein
C, D
165Streptomyces clavuligerusMutation(s): 0
Find proteins for P35804 (Streptomyces clavuligerus)
Go to UniProtKB:  P35804
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.65 Å
  • R-Value Free: 0.222
  • R-Value Work: 0.190
  • Space Group: P 21 21 21
Unit Cell:
Length (Å)Angle (°)
a = 45.799α = 90.00
b = 124.473β = 90.00
c = 157.256γ = 90.00
Software Package:
Software NamePurpose
PHASESphasing
SCALEPACKdata scaling
DENZOdata reduction
CNSrefinement

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2006-04-11
    Type: Initial release
  • Version 1.1: 2008-05-01
    Type: Version format compliance
  • Version 1.2: 2011-07-13
    Type: Version format compliance
  • Version 1.3: 2018-04-18
    Type: Data collection
  • Version 1.4: 2019-12-25
    Type: Advisory, Derived calculations
