1Y4K

Lipoxygenase-1 (Soybean) at 100K, N694G Mutant

Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.95 Å
  • R-Value Free: 0.232
  • R-Value Work: 0.180
  • R-Value Observed: 0.183

wwPDB Validation   3D Report Full Report


This is version 1.4 of the entry. See complete history.


Literature

Kinetic, spectroscopic, and structural investigations of the soybean lipoxygenase-1 first-coordination sphere mutant, Asn694Gly.

Segraves, E.N., Chruszcz, M., Neidig, M.L., Ruddat, V., Zhou, J., Wecksler, A.T., Minor, W., Solomon, E.I., Holman, T.R.

(2006) Biochemistry 45: 10233-10242

  • DOI: 10.1021/bi060577e
  • Primary Citation of Related Structures:
    1Y4K

  • PubMed Abstract:

    • In wild-type soybean LO-1 (WT sLO-1), Asn694 is a weak sixth ligand that is thought to be critical for enzymatic catalysis. In this investigation, N694G sLO-1 was studied to probe its contribution at this sixth ligand position to the kinetic and spectroscopic properties ...

    In wild-type soybean LO-1 (WT sLO-1), Asn694 is a weak sixth ligand that is thought to be critical for enzymatic catalysis. In this investigation, N694G sLO-1 was studied to probe its contribution at this sixth ligand position to the kinetic and spectroscopic properties. The k(cat) value of N694G is approximately 230 times lower than that of WT sLO-1 at 25 degrees C, which can be partially explained by a lowered reduction potential of the iron as seen as a shift in the visible ligand-to-metal charge-transfer band (lambda(max) = 410 nm for N694G and lambda(max) = 425 nm for WT sLO-1). This conclusion was supported by a faster rate of oxidation of N694G by the product than that of WT sLO-1 (k(2) = 606 s(-)(1) for N694G and k(2) = 349 s(-)(1) for WT sLO-1). These results suggest a stronger ligand at the active site iron than the native Asn694, which is confirmed to be a water bound to the Fe(II) in the crystal structure. This produces a six-coordinate circular dichroism/magnetic circular dichroism (CD/MCD) spectra for ferrous N694G and an intermediate rhombic electron paramagnetic resonance (EPR) signal for ferric N694G. The EPR spectrum and its pH dependence suggest that the coordination environment of ferric N694G contains one hydroxide and one water. On the basis of both kinetic and structural factors, we propose that the Asn694 water-derived ligand would likely be a hydroxide and the active site, water-derived ligand a water in the ferric state, hence lowering the reaction rate of N694G more than would be expected from the lowered reduction potential alone.

    Organizational Affiliation:

    Department of Chemistry and Biochemistry, University of California, Santa Cruz, California 95064, USA.



Macromolecules
Find similar proteins by:
(by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
Seed lipoxygenase-1A839Glycine maxMutation(s): 1
Gene Names: LOX1.1, LOX1
EC: 1.13.11.12
UniProt
Find proteins for P08170 (Glycine max)
Explore P08170
Go to UniProtKB:  P08170
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP08170
Protein Feature View
Expand
  • Reference Sequence
Small Molecules
Ligands 3 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
EDO
Query on EDO
Download Ideal Coordinates CCD File
E [auth A]1,2-ETHANEDIOL
C2 H6 O2
LYCAIKOWRPUZTN-UHFFFAOYSA-N		 Ligand Interaction
ACT
Query on ACT
Download Ideal Coordinates CCD File
C [auth A],
D [auth A]		ACETATE ION
C2 H3 O2
QTBSBXVTEAMEQO-UHFFFAOYSA-M		 Ligand Interaction
FE2
Query on FE2
Download Ideal Coordinates CCD File
B [auth A]FE (II) ION
Fe
CWYNVVGOOAEACU-UHFFFAOYSA-N		 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.95 Å
  • R-Value Free: 0.232
  • R-Value Work: 0.180
  • R-Value Observed: 0.183
  • Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 93.884α = 90
b = 92.835β = 90.66
c = 49.435γ = 90
Software Package:
Software NamePurpose
HKL-2000data collection
HKL-2000data reduction
REFMACrefinement
HKL-2000data reduction
HKL-2000data scaling
CNSphasing

Structure Validation

View Full Validation Report



View more in-depth experimental data

Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2005-12-13
    Type: Initial release
  • Version 1.1: 2008-04-30
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Version format compliance
  • Version 1.3: 2021-10-20
    Changes: Database references, Derived calculations
  • Version 1.4: 2022-04-13
    Changes: Database references, Structure summary
