1XRD | pdb_00001xrd

Light-Harvesting Complex 1 Alfa Subunit from Wild-Type Rhodospirillum rubrum


Experimental Data Snapshot

  • Method: SOLUTION NMR
  • Conformers Calculated: 300
  • Conformers Submitted: 10
  • Selection Criteria: structures with the lowest energy

wwPDB Validation 3D Report Full Report

Validation slider image for 1XRD

This is version 1.4 of the entry. See complete history

Literature

Solution Structures of the Core Light-harvesting alpha and beta Polypeptides from Rhodospirillum rubrum: Implications for the Pigment-Protein and Protein-Protein Interactions

Wang, Z.-Y.Gokan, K.Kobayashi, M.Nozawa, T.

(2005) J Mol Biology 347: 465-477

  • DOI: https://doi.org/10.1016/j.jmb.2005.01.017
  • Primary Citation Related Structures:
    1WRG, 1XRD

  • PubMed Abstract:

    We have determined the solution structures of the core light-harvesting (LH1) alpha and beta-polypeptides from wild-type purple photosynthetic bacterium Rhodospirillum rubrum using multidimensional NMR spectroscopy. The two polypeptides form stable alpha helices in organic solution. The structure of alpha-polypeptide consists of a long helix of 32 amino acid residues over the central transmembrane domain and a short helical segment at the N terminus that is followed by a three-residue loop. Pigment-coordinating histidine residue (His29) in the alpha-polypeptide is located near the middle of the central helix. The structure of beta-polypeptide shows a single helix of 32 amino acid residues in the membrane-spanning region with the pigment-coordinating histidine residue (His38) at a position close to the C-terminal end of the helix. Strong hydrogen bonds have been identified for the backbone amide protons over the central helical regions, indicating a rigid property of the two polypeptides. The overall structures of the R.rubrum LH1 alpha and beta-polypeptides are different from those previously reported for the LH1 beta-polypeptide of Rhodobacter sphaeroides, but are very similar to the structures of the corresponding LH2 alpha and beta-polypeptides determined by X-ray crystallography. A model constructed for the structural subunit (B820) of LH1 complex using the solution structures reveals several important features on the interactions between the LH1 alpha and beta-polypeptides. The significance of the N-terminal regions of the two polypeptides for stabilizing both B820 and LH1 complexes, as clarified by many experiments, may be attributed to the interactions between the short N-terminal helix (Trp2-Gln6) of alpha-polypeptide and a GxxxG motif in the beta-polypeptide.


  • Organizational Affiliation
    • Department of Biomolecular Engineering, Graduate School of Engineering, Tohoku University, Aramaki-aza, Aoba, Aoba-ku, Sendai 980-8579, Japan. wang@biophys.che.tohoku.ac.jp

Macromolecule Content

  • Total Structure Weight: 6.08 kDa
  • Atom Count: 432
  • Modeled Residue Count: 52
  • Deposited Residue Count: 52
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Light-harvesting protein B-880, alpha chain52Rhodospirillum rubrumMutation(s): 0
Membrane Entity: Yes
UniProt
Find proteins for P02947 (Rhodospirillum rubrum)
Explore P02947
Go to UniProtKB:  P02947
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP02947
Sequence Annotations
Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

  • Method: SOLUTION NMR
  • Conformers Calculated: 300
  • Conformers Submitted: 10
  • Selection Criteria: structures with the lowest energy

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2005-03-15
    Type: Initial release
  • Version 1.1: 2008-04-30
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Version format compliance
  • Version 1.3: 2022-03-02
    Changes: Database references, Derived calculations
  • Version 1.4: 2024-05-29
    Changes: Data collection
