1X46

Crystal structure of a hemoglobin component (TA-VII) from Tokunagayusurika akamusi


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.5 Å
  • R-Value Free: 0.227
  • R-Value Work: 0.194

wwPDB Validation 3D Report Full Report


This is version 1.2 of the entry. See complete history

Literature

Crystal structures of two hemoglobin components from the midge larva Propsilocerus akamusi (Orthocladiinae, Diptera).

Kuwada, T.Hasegawa, T.Sato, S.Sato, I.Ishikawa, K.Takagi, T.Shishikura, F.

(2007) Gene 398: 29-34

  • DOI: 10.1016/j.gene.2007.02.049
  • Primary Citation of Related Structures:

  • PubMed Abstract:
  • The polymorphic components of hemoglobin (Hb) of the midge larva Propsilocerus akamusi were classified into two distinct types dependent on their spectroscopic properties, normal absorption (N) and low absorption (L). Analyses of the amino acid seque ...

    The polymorphic components of hemoglobin (Hb) of the midge larva Propsilocerus akamusi were classified into two distinct types dependent on their spectroscopic properties, normal absorption (N) and low absorption (L). Analyses of the amino acid sequences of component VII (N-type Hb) and component V (L-type Hb) from P. akamusi indicated that one remarkable difference is the replacement of the distal histidine (His) with isoleucine (Ile) in component V. To clarify the structural differences between the two Hb components, we determined the crystal structures of components V and VII at resolutions of 1.64 A and 1.50 A, respectively. These crystal structures indicated a short additional helix comprising three amino acid residues at the C-terminal region in component V, and a typical globin fold including eight helices in component VII. Comparison of the heme regions of the Hb components suggests that the structural changes of the heme region in component V on ligation differ from that of usual Hb.


    Organizational Affiliation

    Advanced Research Institute for the Sciences and Humanities, Nihon University, Chiyoda-ku, Tokyo 102-8251, Japan.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
hemoglobin component VII
A
150Tokunagayusurika akamusiMutation(s): 0
Find proteins for Q7M421 (Tokunagayusurika akamusi)
Go to UniProtKB:  Q7M421
Small Molecules
Ligands 1 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
HEM
Query on HEM

Download SDF File
Download CCD File
A
PROTOPORPHYRIN IX CONTAINING FE
HEME
C34 H32 Fe N4 O4
KABFMIBPWCXCRK-RGGAHWMASA-L
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.5 Å
  • R-Value Free: 0.227
  • R-Value Work: 0.194
  • Space Group: C 2 2 21
Unit Cell:
Length (Å)Angle (°)
a = 42.010α = 90.00
b = 69.110β = 90.00
c = 99.650γ = 90.00
Software Package:
Software NamePurpose
CrystalCleardata scaling
CNXphasing
CNXrefinement
CrystalCleardata reduction

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2005-05-24
    Type: Initial release
  • Version 1.1: 2008-04-30
    Type: Version format compliance
  • Version 1.2: 2011-07-13
    Type: Version format compliance
