Experimental Data Snapshot

  • Resolution: 1.50 Å
  • R-Value Free: 0.255
  • R-Value Work: 0.189
  • R-Value Observed: 0.189

wwPDB Validation   3D Report Full Report

This is version 1.3 of the entry. See complete history


The crystal structure of ribosomal protein L14 reveals an important organizational component of the translational apparatus.

Davies, C.White, S.W.Ramakrishnan, V.

(1996) Structure 4: 55-66

  • DOI: https://doi.org/10.1016/s0969-2126(96)00009-3
  • Primary Citation of Related Structures:

  • PubMed Abstract:

    Detailed structural information on ribosomal proteins has increased our understanding of the structure, function and evolution of the ribosome. L14 is one of the most conserved ribosomal proteins and appears to have a central role in the ribonucleoprotein complex. Studies have indicated that L14 occupies a central location between the peptidyl transferase and GTPase regions of the large ribosomal subunit. The crystal structure of L14 from Bacillus stearothermophilus has been solved using a combination of isomorphous replacement and multiwavelength anomalous dispersion (MAD) methods. The structure comprises a five-stranded beta-barrel, a C-terminal loop region that contains two small alpha-helices, and a beta-ribbon that projects from the beta-barrel. An analysis of the structure and the conserved amino acids reveals three surface patches that probably mediate L14-RNA and L14-protein interactions within the ribosome. The accepted role of ribosomal proteins is to promote the folding and stabilization of ribosomal RNA. The L14 structure is consistent with this notion, and it suggests that the RNA binds in two sites. One RNA-binding site appears to recognize a distinct region of ribosomal RNA during particle assembly. The second site is smaller and may become occupied during the later compaction of the RNA. The surface hydrophobic patch is a likely site of protein-protein interaction, possibly with L19.

  • Organizational Affiliation

    Department of Microbiology, Duke University Medical Center, Durham, NC 27710, USA.

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
RIBOSOMAL PROTEIN L14122Geobacillus stearothermophilusMutation(s): 0
Find proteins for P04450 (Geobacillus stearothermophilus)
Explore P04450
Go to UniProtKB:  P04450
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP04450
Sequence Annotations
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Resolution: 1.50 Å
  • R-Value Free: 0.255
  • R-Value Work: 0.189
  • R-Value Observed: 0.189
  • Space Group: C 1 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 66.9α = 90
b = 32.7β = 101.8
c = 49.4γ = 90
Software Package:
Software NamePurpose
X-PLORmodel building
MOSFLMdata reduction

Structure Validation

View Full Validation Report

Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 1996-08-17
    Type: Initial release
  • Version 1.1: 2008-03-24
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Version format compliance
  • Version 1.3: 2024-02-14
    Changes: Data collection, Database references, Other
