1VPZ | pdb_00001vpz

Crystal structure of a putative carbon storage regulator protein (csra, pa0905) from pseudomonas aeruginosa at 2.05 A resolution

• PDB DOI: https://doi.org/10.2210/pdb1VPZ/pdb

• Classification: RNA BINDING PROTEIN
• Organism(s): Pseudomonas aeruginosa
• Expression System: Escherichia coli
• Mutation(s): Yes


• Deposited: 2004-11-24 Released: 2004-12-14
• Deposition Author(s): Joint Center for Structural Genomics (JCSG)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.05 Å
• R-Value Free:
  0.275 (Depositor), 0.270 (DCC)
• R-Value Work:
  0.218 (Depositor), 0.230 (DCC)
• R-Value Observed:
  0.221 (Depositor)

Literature

Crystal structure of the global regulatory protein CsrA from Pseudomonas putida at 2.05 A resolution reveals a new fold.

Rife, C., Schwarzenbacher, R., McMullan, D., Abdubek, P., Ambing, E., Axelrod, H., Biorac, T., Canaves, J.M., Chiu, H.J., Deacon, A.M., DiDonato, M., Elsliger, M.A., Godzik, A., Grittini, C., Grzechnik, S.K., Hale, J., Hampton, E., Han, G.W., Haugen, J., Hornsby, M., Jaroszewski, L., Klock, H.E., Koesema, E., Kreusch, A., Kuhn, P., Lesley, S.A., Miller, M.D., Moy, K., Nigoghossian, E., Paulsen, J., Quijano, K., Reyes, R., Sims, E., Spraggon, G., Stevens, R.C., van den Bedem, H., Velasquez, J., Vincent, J., White, A., Wolf, G., Xu, Q., Hodgson, K.O., Wooley, J., Wilson, I.A.

(2005) Proteins 61: 449-453

• PubMed: 16104018
• DOI: https://doi.org/10.1002/prot.20502
• Primary Citation of Related Structures:
  1VPZ

---

Organizational Affiliation:
• The Joint Center for Structural Genomics, Stanford University, Menlo Park, California, USA.

Biological Assembly 1

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 1 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 17.04 kDa
• Atom Count: 902
• Modeled Residue Count: 113
• Deposited Residue Count: 146
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Carbon storage regulator homolog	A, B	73	Pseudomonas aeruginosa	Mutation(s): 2  Gene Names: csrA
UniProt
Find proteins for O69078 (Pseudomonas aeruginosa (strain ATCC 15692 / DSM 22644 / CIP 104116 / JCM 14847 / LMG 12228 / 1C / PRS 101 / PAO1)) Explore O69078  Go to UniProtKB:  O69078

Small Molecules

Modified Residues  1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE	A, B	L-PEPTIDE LINKING	C5 H11 N O2 Se		MET

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.05 Å
• R-Value Free:  0.275 (Depositor), 0.270 (DCC)
• R-Value Work:  0.218 (Depositor), 0.230 (DCC)
• R-Value Observed: 0.221 (Depositor)

Diffraction Data: https://doi.org/10.18430/M31VPZ

Space Group: C 2 2 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 49.066	α = 90
b = 56.669	β = 90
c = 98.533	γ = 90

Software Package:

Software Name	Purpose
MOSFLM	data reduction
SCALA	data scaling
SOLVE	phasing
REFMAC	refinement
CCP4	data scaling

Structure Validation

Entry History

Deposition Data

• Released Date: 2004-12-14
Deposition Author(s): Joint Center for Structural Genomics (JCSG)

Revision History

• Version 1.0: 2004-12-14
  Type: Initial release

• Version 1.1: 2008-04-26
  Changes: Version format compliance
• Version 1.2: 2011-07-13
  Changes: Advisory, Version format compliance
• Version 1.3: 2017-10-04
  Changes: Refinement description
• Version 1.4: 2023-01-25
  Changes: Database references, Derived calculations
• Version 1.5: 2024-11-13
  Changes: Data collection, Refinement description, Structure summary
