Macromolecule Content

Total Structure Weight: 94.79 kDa
Atom Count: 7037
Modelled Residue Count: 802
Deposited Residue Count: 820
Unique protein chains: 1

1VME

Crystal structure of Flavoprotein (TM0755) from Thermotoga maritima at 1.80 A resolution

PDB DOI: 10.2210/pdb1VME/pdb

Classification: ELECTRON TRANSPORT
Organism(s): Thermotoga maritima
Expression System: Escherichia coli
Mutation(s): Yes

Deposited: 2004-09-21 Released: 2004-09-28
Deposition Author(s): Joint Center for Structural Genomics (JCSG)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.80 Å
R-Value Free: 0.181
R-Value Work: 0.147
R-Value Observed: 0.149

wwPDB Validation 3D Report Full Report

This is version 1.2 of the entry. See complete history.

Literature

Crystal structure of Flavoprotein (TM0755) from Thermotoga maritima at 1.80 A resolution

Joint Center for Structural Genomics (JCSG)

To be published.

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Flavoprotein	A, B	410	Thermotoga maritima	Mutation(s): 7 Gene Names: TM0755
UniProt
Find proteins for Q9WZL4 (Thermotoga maritima (strain ATCC 43589 / DSM 3109 / JCM 10099 / NBRC 100826 / MSB8)) Explore Q9WZL4 Go to UniProtKB: Q9WZL4
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	Q9WZL4
Protein Feature View Expand
Reference Sequence

Small Molecules

Ligands 3 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
FEO Query on FEO Download Ideal Coordinates CCD File SDF format, chain I [auth B] SDF format, chain E [auth A] MOL2 format, chain I [auth B] MOL2 format, chain E [auth A]	E [auth A], I [auth B]	MU-OXO-DIIRON Fe₂ O NPMYUMBHPJGBFA-UHFFFAOYSA-N		Ligand Interaction
EDO Query on EDO Download Ideal Coordinates CCD File SDF format, chain F [auth A] SDF format, chain G [auth A] SDF format, chain J [auth B] MOL2 format, chain F [auth A] MOL2 format, chain G [auth A] MOL2 format, chain J [auth B]	F [auth A], G [auth A], J [auth B]	1,2-ETHANEDIOL C₂ H₆ O₂ LYCAIKOWRPUZTN-UHFFFAOYSA-N		Ligand Interaction
CL Query on CL Download Ideal Coordinates CCD File SDF format, chain C [auth A] SDF format, chain D [auth A] SDF format, chain H [auth B] MOL2 format, chain C [auth A] MOL2 format, chain D [auth A] MOL2 format, chain H [auth B]	C [auth A], D [auth A], H [auth B]	CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M		Ligand Interaction

Modified Residues 1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE Query on MSE	A, B	L-PEPTIDE LINKING	C₅ H₁₁ N O₂ Se		MET

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.80 Å
R-Value Free: 0.181
R-Value Work: 0.147
R-Value Observed: 0.149
Space Group: P 1 2₁ 1
Diffraction Data DOI: 10.18430/M31VME Protein Diffraction

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 55.242	α = 90
b = 95.831	β = 95.43
c = 90.13	γ = 90

Software Package:

Software Name	Purpose
MOSFLM	data reduction
SCALA	data scaling
SOLVE	phasing
REFMAC	refinement
CCP4	data scaling

Structure Validation

View Full Validation Report

Entry History

Deposition Data

Deposited Date: 2004-09-21
Released Date: 2004-09-28

Deposition Author(s):

Joint Center for Structural Genomics (JCSG)

Revision History (Full details and data files)

Version 1.0: 2004-09-28
Type: Initial release
Version 1.1: 2008-04-26
Changes: Version format compliance
Version 1.2: 2011-07-13
Changes: Advisory, Version format compliance
