1VDK

Crystal structure of fumarase from thermus thermophilus HB8

• PDB DOI: https://doi.org/10.2210/pdb1VDK/pdb

• Classification: LYASE
• Organism(s): Thermus thermophilus HB8
• Expression System: Escherichia coli BL21(DE3)
• Mutation(s): No


• Deposited: 2004-03-23 Released: 2004-04-13
• Deposition Author(s): Mizutani, H., Kunishima, N., RIKEN Structural Genomics/Proteomics Initiative (RSGI)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.80 Å
• R-Value Free: 0.201
• R-Value Work: 0.185
• R-Value Observed: 0.186

Starting Model: experimental

Literature

Crystal structure of fumarase from thermus thermophilus HB8

Mizutani, H., Kunishima, N.

To be published.

Biological Assembly 1

Global Symmetry: Dihedral - D2  (Explore in 3D)
Global Stoichiometry: Homo 4-mer - A4

Biological assembly 1 assigned by authors and generated by PISA,PQS (software)

Macromolecule Content

• Total Structure Weight: 101.88 kDa
• Atom Count: 7,680
• Modelled Residue Count: 915
• Deposited Residue Count: 932
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Fumarate hydratase class II	A, B	466	Thermus thermophilus HB8	Mutation(s): 0  EC: 4.2.1.2
UniProt
Find proteins for P84127 (Thermus thermophilus) Explore P84127  Go to UniProtKB:  P84127

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.80 Å
• R-Value Free: 0.201
• R-Value Work: 0.185
• R-Value Observed: 0.186
• Space Group: C 2 2 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 125.336	α = 90
b = 140.122	β = 90
c = 135.372	γ = 90

Software Package:

Software Name	Purpose
CNS	refinement
HKL-2000	data reduction
SCALEPACK	data scaling
MOLREP	phasing

Structure Validation

Entry History

Deposition Data

• Released Date: 2004-04-13
Deposition Author(s): Mizutani, H., Kunishima, N., RIKEN Structural Genomics/Proteomics Initiative (RSGI)

Revision History

• Version 1.0: 2004-04-13
  Type: Initial release

• Version 1.1: 2008-04-27
  Changes: Version format compliance
• Version 1.2: 2011-07-13
  Changes: Derived calculations, Source and taxonomy, Version format compliance
• Version 1.3: 2023-10-25
  Changes: Data collection, Database references, Refinement description
