1V9M

Crystal structure of the C subunit of V-type ATPase from Thermus thermophilus


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.85 Å
  • R-Value Free: 0.228
  • R-Value Work: 0.202

wwPDB Validation   3D Report Full Report


This is version 1.2 of the entry. See complete history


Literature

Structure of the C subunit of V-type ATPase from Thermus thermophilus at 1.85 A resolution.

Numoto, N.Kita, A.Miki, K.

(2004) Acta Crystallogr D Biol Crystallogr 60: 810-815

  • DOI: 10.1107/S0907444904003257
  • Primary Citation of Related Structures:
    1V9M

  • PubMed Abstract:
  • The V-type H(+)-ATPases are similar to the F-type ATP synthases in their structure and functional mechanism. They hydrolyze ATP coupled with proton translocation across a membrane, but in some archaea and eubacteria they also synthesize ATP in the reverse reaction ...

    The V-type H(+)-ATPases are similar to the F-type ATP synthases in their structure and functional mechanism. They hydrolyze ATP coupled with proton translocation across a membrane, but in some archaea and eubacteria they also synthesize ATP in the reverse reaction. The C subunit is one of the components of the membrane-bound V(0) moiety of V-type ATPases. The C subunit of V-type H(+)-ATPase from Thermus thermophilus was crystallized in a monoclinic form and its crystal structure was determined at 1.85 A resolution by the MAD method using selenomethionyl protein. The structure has a cone (tapered cylinder) shape consisting of only two types of helix (long and short) as secondary-structure elements. The molecule is divided into three similar domains, each of which has essentially the same topology. On the basis of the structural features and molecular-surface charge distribution, it is suggested that the bottom side of the C subunit is a possible binding site for the V(0) proteolipid L-subunit ring and that the C subunit might function as a spacer unit between the proteolipid L-subunit ring and the rotating V(1) central shaft.


    Organizational Affiliation

    Department of Chemistry, Graduate School of Science, Kyoto University, Sakyo-ku, Kyoto 606-8502, Japan.



Macromolecules
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
V-type ATP synthase subunit CA323Thermus thermophilusMutation(s): 0
EC: 3.6.3.14
UniProt
Find proteins for P74902 (Thermus thermophilus (strain ATCC 27634 / DSM 579 / HB8))
Explore P74902
Go to UniProtKB:  P74902
Protein Feature View
Expand
  • Reference Sequence
Small Molecules
Ligands 1 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
GOL
Query on GOL

Download Ideal Coordinates CCD File
B [auth A], C [auth A]GLYCEROL
C3 H8 O3
PEDCQBHIVMGVHV-UHFFFAOYSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.85 Å
  • R-Value Free: 0.228
  • R-Value Work: 0.202
  • Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 41.79α = 90
b = 83.806β = 113.86
c = 48.567γ = 90
Software Package:
Software NamePurpose
CNSrefinement
HKL-2000data reduction
SCALEPACKdata scaling
SOLVEphasing

Structure Validation

View Full Validation Report




Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2004-05-04
    Type: Initial release
  • Version 1.1: 2008-04-27
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Non-polymer description, Version format compliance
