1U59

Crystal Structure of the ZAP-70 Kinase Domain in Complex with Staurosporine


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.30 Å
  • R-Value Free: 0.271
  • R-Value Work: 0.217

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.3 of the entry. See complete history


Literature

The Three-dimensional Structure of the ZAP-70 Kinase Domain in Complex with Staurosporine: IMPLICATIONS FOR THE DESIGN OF SELECTIVE INHIBITORS

Jin, L.Pluskey, S.Petrella, E.C.Cantin, S.M.Gorga, J.C.Rynkiewicz, M.J.Pandey, P.Strickler, J.E.Babine, R.E.Weaver, D.T.Seidl, K.J.

(2004) J Biol Chem 279: 42818-42825

  • DOI: 10.1074/jbc.M407096200
  • Primary Citation of Related Structures:
    1U59

  • PubMed Abstract:
  • The ZAP-70 tyrosine kinase plays a critical role in T cell activation and the immune response and therefore is a logical target for immunomodulatory therapies. Although the crystal structure of the tandem Src homology-2 domains of human ZAP-70 in complex with a peptide derived from the zeta subunit of the T cell receptor has been reported (Hatada, M ...

    The ZAP-70 tyrosine kinase plays a critical role in T cell activation and the immune response and therefore is a logical target for immunomodulatory therapies. Although the crystal structure of the tandem Src homology-2 domains of human ZAP-70 in complex with a peptide derived from the zeta subunit of the T cell receptor has been reported (Hatada, M. H., Lu, X., Laird, E. R., Green, J., Morgenstern, J. P., Lou, M., Marr, C. S., Phillips, T. B., Ram, M. K., Theriault, K., Zoller, M. J., and Karas, J. L. (1995) Nature 377, 32-38), the structure of the kinase domain has been elusive to date. We crystallized and determined the three-dimensional structure of the catalytic subunit of ZAP-70 as a complex with staurosporine to 2.3 A resolution, utilizing an active kinase domain containing residues 327-606 identified by systematic N- and C-terminal truncations. The crystal structure shows that this ZAP-70 kinase domain is in an active-like conformation despite the lack of tyrosine phosphorylation in the activation loop. The unique features of the ATP-binding site, identified by structural and sequence comparison with other kinases, will be useful in the design of ZAP-70-selective inhibitors.


    Organizational Affiliation

    Daiichi Asubio Medical Research Laboratories LLC, Cambridge, MA 02139, USA. lei.jin@daiamed.com



Macromolecules
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
Tyrosine-protein kinase ZAP-70A287Homo sapiensMutation(s): 0
Gene Names: ZAP70SRK
EC: 2.7.1.112 (PDB Primary Data), 2.7.10.2 (UniProt)
UniProt & NIH Common Fund Data Resources
Find proteins for P43403 (Homo sapiens)
Explore P43403
Go to UniProtKB:  P43403
PHAROS:  P43403
Protein Feature View
Expand
  • Reference Sequence
Small Molecules
Ligands 1 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
STU (Subject of Investigation/LOI)
Query on STU

Download Ideal Coordinates CCD File
B [auth A]STAUROSPORINE
C28 H26 N4 O3
HKSZLNNOFSGOKW-FYTWVXJKSA-N
 Ligand Interaction
Binding Affinity Annotations
IDSourceBinding Affinity
STO BindingDB:  1U59 Kd: 44 (nM) from 1 assay(s)
IC50: min: 1.2, max: 8.6 (nM) from 4 assay(s)
PDBBind:  1U59 IC50: 55.8 (nM) from 1 assay(s)
STU Binding MOAD:  1U59 IC50: 55.8 (nM) from 1 assay(s)
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.30 Å
  • R-Value Free: 0.271
  • R-Value Work: 0.217
  • Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 43.056α = 90
b = 57.064β = 90
c = 125.133γ = 90
Software Package:
Software NamePurpose
CNXrefinement
HKL-2000data scaling
AMoREphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2004-08-17
    Type: Initial release
  • Version 1.1: 2008-04-30
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Version format compliance
  • Version 1.3: 2017-10-11
    Changes: Refinement description
